纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-300-00[01]) - BOOM CYLINDER - RIGHT (WITHOUT VALVE, PRESSURE RELIEF) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
669 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | KUV10010 | [1] | HYDRAULIC CYLINDER | SUM |
| 1. | LR00455 | [1] | HYD CYL SLEEVE | SUM |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | KUV0037 | [1] | BUSHING | SUM |
| 4. | LB010960 | [1] | PISTON ROD | SUM |
| 6. | KUV0036 | [1] | BUSHING | SUM |
| 8. | LU002220 | [1] | CYLINDER END CAP | SUM |
| 9. | LB00460 | [1] | BUSHING | SUM |
| 10. | LA00622 | [1] | RING | SUM |
| 11. | LE012420 | [1] | RING | SUM |
| 12. | LAU0070 | [1] | RING | SUM |
| 13. | LE00616 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 14. | LE00980 | [1] | RING | SUM Superseded by part number: LE015230 |
| 15. | 154877A1 | [1] | O-RING | SUM |
| 16. | LE00619 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 17. | 108R030W100N | [8] | BOLT | SUMM30 x 100 |
| 18. | LE00986 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 19. | LE00620 | [1] | SEAL | SUM |
| 20.. | LJ00625 | [1] | JACK PISTON | SUM |
| 21. | LE00621 | [1] | RING | SUM |
| 22. | LE012480 | [2] | SCRAPER RING | SUM |
| 23. | LE00623 | [2] | SEALING STRIP | SUM |
| 24. | LH00212 | [1] | SHIM | SUM |
| 25. | LA00910 | [1] | SPECIAL NUT | SUM |
| 26. | LA00617 | [1] | SCREW,Hex Skt | SUM |
| 27. | LB00459 | [1] | BALL | SUM |
| 28. | LE00653 | [4] | WIPER SEAL | SUM |
| 29. | LR012350 | [1] | HYD. TUBE | SUM |
| 30. | LR012360 | [1] | HYD. TUBE | SUM Superseded by part number: LR018850 |
| 31. | 154579A1 | [2] | O-RING | SUM |
| 32. | LA00751 | [8] | BOLT,Hex Skt Hd | SUM |
| 33. | LD001220 | [1] | CLAMP BRACKET | SUM |
| 34. | LD00020 | [1] | CLAMP BRACKET | SUM |
| 35. | 158131A1 | [4] | BOLT,High Strength, M10 x 1.5 x 35mm, Cl 10.9 | SUM |
| 36. | 156227A1 | [4] | WASHER | SUM |
| 37. | 155736A1 | [1] | HALF-FLANGE | SUM Superseded by part number: LS003200 |
| 38. | LA00616 | [1] | BOLT | SUM |
| 39. | 892-16014 | [1] | LOCK WASHER,M14, Hvy | SUM |
| 40. | LD00021 | [1] | CLAMP BRACKET | SUM |
| 41. | LS00104 | [2] | PIPE ASSY. | SUM |
| 42. | KAB0004 | [1] | BOLT | SUM |
| 43. | LUU0024 | [1] | SPRING WASHER | SUM |
| 44. | LJ00624 | [1] | BLEEDER | SUM |
| 45. | M01X0813 | [1] | NIPPLE, LUBE | SUM |
| 47. | LZ007110 | [1] | SEAL KIT | SUM |
