纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-305-00[01]) - DIPPER CYLINDER - BOOM (7.25 M) - (WITH VALVE, PRESSURE RELIEF) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
714 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | KUV10390 | [1] | HYDRAULIC CYLINDER | SUM |
| 1. | LR00750 | [1] | HYD CYL SLEEVE | SUM |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | KUV0037 | [1] | BUSHING | SUM |
| 4. | LB010970 | [1] | PISTON ROD | SUM |
| 8. | LU002240 | [1] | CYLINDER END CAP | SUM |
| 9. | LB00461 | [1] | BUSHING | SUM |
| 10. | LA00623 | [1] | LOCKING RING | SUM |
| 11. | LE012430 | [1] | RING | SUM |
| 12. | LE00485 | [1] | WIPER SEAL | SUM |
| 13. | LE00486 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 14. | LE00911 | [1] | WIPER SEAL | SUM |
| 15. | 154893A1 | [1] | O-RING | SUM |
| 16. | LE012370 | [1] | BACK-UP RING | SUM |
| 17. | 108R033W110N | [8] | BOLT | SUMM33 x 110 |
| 18. | LE00912 | [1] | RING | SUM |
| 19. | LJ00627 | [1] | JACK PISTON | SUM |
| 20. | LE00628 | [1] | SEALING RING | SUMSEALRING |
| 21. | LE012490 | [2] | SCRAPER RING | SUM |
| 22. | LE00630 | [2] | SEALING STRIP | SUM |
| 23. | LH00213 | [1] | SEALING STRIP | SUM |
| 24. | LA010170 | [1] | SPECIAL NUT | SUM |
| 25. | LA00617 | [1] | SCREW,Hex Skt | SUM |
| 26. | LB00459 | [1] | BALL | SUM |
| 27. | LE00653 | [4] | WIPER SEAL | SUM |
| 28. | LJ00624 | [1] | BLEEDER | SUM |
| 30. | LZ007120 | [1] | SEAL KIT | SUM |
