神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-027) - CYLINDER ASSY (ARM) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
814 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1948F1 | [1] | CYLINDER | KOB(ARM) |
| 1. | 2438U1948S2 | [1] | PISTON ROD | KOBTUBE, CYLINDER |
| 2. | 2438U1948S2 | [1] | PISTON ROD | KOB |
| 3. | 2438U1948S3 | [1] | AIR CONDITIONER | KOB |
| 4. | 2438U999S4 | [1] | BUSHING | KOB |
| 5. | 2438U999S5 | [1] | RING | KOB |
| 6. | 2438U999S6 | [1] | BACK-UP RING | KOBBUFFER |
| 7. | 2438U999S7 | [1] | RING | KOB |
| 8. | 2438U999S8 | [1] | RING | KOB |
| 9. | 2438U999S9 | [1] | RING | KOBSLIDE |
| 11. | ZD12P12000 | [1] | O-RING | KOB |
| 12. | 2438U959S12 | [1] | BACK-UP RING | KOB |
| 13. | ZS23C20070 | [8] | SCREW,Hex Socket Head, M20 x 70mm | KOBM20x2.5x70mm |
| 14. | 2438U1135S14 | [1] | BEARING CUP | KOB |
| 15. | 2438U1135S15 | [1] | OIL SEAL | KOB |
| 16. | 2438U1948S16 | [1] | PISTON | KOB |
| 17. | 2438U1382S15 | [1] | SEAL | KOB |
| 18. | 2438U959S16 | [2] | RING | KOBSLIDE |
| 19. | 2438U1382S17 | [2] | RING | KOBSLIDE |
| 20. | 2438U1948S20 | [1] | SHIM | KOB |
| 21. | 2438U1948S21 | [1] | NUT | KOB |
| 22. | 2438U999S21 | [1] | SET SCREW | KOBSet -- M12x1.75mm |
| 23. | 2436U330S16 | [1] | BALL | KOB |
| 24. | 2438U1948S24 | [1] | BEARING | KOB |
| 25. | 2438U1104S24 | [1] | OIL SEAL | KOBCUSHION |
| 26. | 2438U1104S25 | [2] | STOP | KOB |
| 27. | 2438U1948S27 | [1] | RING | KOB |
| 28. | 2438U1948S28 | [2] | BUSHING | KOB |
| 29. | 2438U1102S31 | [4] | SEAL | KOB |
| 30. | 2438U1948S30 | [1] | U-BRACKET | KOB |
| 31. | 2438U959S25 | [1] | BAND | KOB |
| 32. | 2438U1102S29 | [2] | SCREW | KOB Superseded by part number: ZS18C10035 |
| 35. | 2438U1135S35 | [1] | RING | KOBWIPER |
| . . | 2438U1948R400 | [1] | REPAIR KIT | KOBHEAD, CONSISTS OF REF 6 - 9, 11, 12 & 35 |
| . . | 2438U1948R200 | [1] | REPAIR KIT | KOBPISTON, CONSISTS OF REF 15, 17 - 91 & 25 |
| . . | 2438U1948R500 | [1] | SEAL KIT | KOBCOMPLETE, CONSISTS OF REF 6 - 9, 11, 12, 15, 17 - 19, 25 & 35 |
