神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-028) - CYLINDER ASSY (BUCKET) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
702 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U1949F1 | [1] | CYLINDER | KOB(BUCKET) |
| 1. | 2438U1949S1 | [1] | TUBE | KOB |
| 2. | 2438U1949S2 | [1] | PISTON ROD | KOB |
| 3. | 2438U1949S3 | [1] | CYLINDER HEAD | KOB |
| 4. | 2438U1949S4 | [1] | BUSHING | KOB |
| 5. | 2438U1949S5 | [1] | RING | KOB |
| 6. | 2438U1949S6 | [1] | BACK-UP RING | KOB |
| 7. | 2438U814S31 | [1] | RING | KOB |
| 8. | 2438U814S32 | [1] | RING | KOB |
| 9. | 2438U1949S9 | [1] | RING | KOBSLIDE |
| 11. | ZD12G10500 | [1] | O-RING,104.40mm ID x 110.60mm OD x 3.10mm | KOBID 14.80 ± 0.20 x OD 19mm |
| 12. | 2438U1949S12 | [1] | RING | KOB |
| 13. | 2438U1949S13 | [8] | SCREW,Hex Socket Head, M18 x 55mm | KOB Superseded by part number: ZS23C18055 |
| 14. | 2438U1949S14 | [1] | PISTON | KOB |
| 15. | 2438U716S23 | [1] | SEAL | KOB |
| 16. | 2438U1949S16 | [2] | SLIDE | KOB |
| 17. | 2438U1949S17 | [2] | SLIDE | KOB |
| 18. | 2438U1946S20 | [1] | SHIM | KOB |
| 19. | 2438U1946S21 | [1] | NUT | KOB |
| 20. | 2438U999S21 | [1] | SET SCREW | KOBSet -- M12x1.75mm |
| 21. | 2436U330S16 | [1] | BALL | KOB |
| 22. | 2438U1949S22 | [1] | BUSHING,70mm ID x 80mm OD x 90mm W | KOB Superseded by part number: YM01V01010P1 |
| 23. | 2438U1949S23 | [4] | RING | KOBWIPER |
| 24. | 2438U1949S24 | [1] | BUSHING,70mm ID x 80mm OD x 90mm W | KOB |
| 25. | 2438U1949S25 | [1] | U-BRACKET | KOB |
| 26. | 2438U1949S26 | [1] | BAND | KOB |
| 27. | 2438U1102S29 | [2] | SCREW | KOB Superseded by part number: ZS18C10035 |
| 28. | 2438U999S30 | [2] | LOCK WASHER | KOB Superseded by part number: ZW26X10000 |
| 35. | LP01V00007S009 | [1] | RING | KOB |
| . . | 2438U1949R400 | [1] | REPAIR KIT | KOBHEAD, CONSISTS OF REF 6 - 9, 11, 12 & 35 |
| . . | 2438U1949R200 | [1] | REPAIR KIT | KOBPISTON, CONSISTS OF REFS 15 - 17 |
| . . | 2438U1949R500 | [1] | REPAIR KIT | KOBCOMPLETE, CONSISTS OF REF 6 - 9, 11, 12, 15 - 17 & 35 |
