纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (09-003-00[01]) - UPPERSTRUCTURE LOWER PANELS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
718 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | KUB10390 | [1] | COVER | SUM |
| 3. | KUB10490 | [1] | COVER | SUM |
| 4. | KUB10500 | [1] | COVER | SUM |
| 5. | KUB10400 | [1] | COVER | SUM |
| 6. | KUB10540 | [1] | COVER | SUM |
| 7. | KWB10050 | [1] | COVER | SUM |
| 8. | KWB10060 | [1] | COVER | SUM |
| 9. | KWB10070 | [1] | COVER | SUM |
| 10. | KUB10460 | [1] | COVER | SUM |
| 11. | KUB10410 | [1] | COVER | SUM |
| 12. | KUB10420 | [1] | COVER | SUM |
| 13. | KUB10430 | [1] | COVER | SUM |
| 14. | KUB10440 | [1] | COVER | SUM |
| 15. | KUB10450 | [3] | COVER | SUM |
| 16. | KRB10520 | [2] | COVER | SUM |
| 17. | 162278A1 | [57] | BOLT | SUM |
| 18. | KUB10470 | [12] | SPACER | SUM |
| 19. | KUB10480 | [8] | SPACER | SUM |
| 20. | KHB10640 | [6] | WASHER | SUM |
| 21. | 167893A1 | [6] | BOLT | SUM |
| 22. | 827-12050 | [8] | BOLT,Hex, M12 x 1.75 x 50mm, Cl 10.9 | CAS Superseded by part number: 337476 |
| 23. | 150811A1 | [8] | WASHER | SUMW12 Superseded by part number: 86625255 |
