纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (09-005-00[01]) - SELF-DETACHING COUNTERWEIGHT SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
477 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUB0157 | [1] | ARM | SUM |
| 2. | 153630A1 | [4] | LUBE NIPPLE | SUM |
| 3. | KUB0173 | [1] | PIN | SUM |
| 4. | 150814A1 | [4] | WASHER,17mm ID x 32mm OD x 4.5mm Thk | SUMW16 |
| 5. | KUB0175 | [2] | PLATE | SUM |
| 6. | 166348A1 | [4] | BOLT | SUMM16 x 45 |
| 7. | KUB0163 | [2] | PLATE | SUM |
| 8. | 105R020Y050R | [4] | BOLT | SUMM20 x 50 |
| 9. | KUB0162 | [2] | PLATE | SUM |
| 10. | 166352A1 | [4] | BOLT | SUMM12 x 30 |
| 11. | KUB0154 | [1] | HYDRAULIC CYLINDER | SUM |
| 12. | KUB0155 | [1] | HYDRAULIC CYLINDER | SUM |
| 13. | KUB0177 | [2] | PIN | SUM |
| 14. | 102R012Y150R | [2] | BOLT | SUMM12 x 150 |
| 15. | 829-1412 | [4] | NUT,M12, Cl 10 | CAS Superseded by part number: 337475 |
| 16. | KUB0167 | [1] | PIN | SUM |
| 17. | KUB0168 | [2] | PLATE | SUM |
| 22. | KUB0169 | [1] | PIN | SUM |
| 24. | 814-10100 | [1] | BOLT,Hex, M10 x 1.5 x 100mm, Cl 8.8 | CAS Superseded by part number: 120075 |
| 25. | 829-1410 | [2] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
| 36. | KUB0190 | [1] | PIN | SUM |
| 37. | 102R012Y140R | [2] | BOLT | SUMM12 x 140 |
| 118. | KAJ3534 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1550.00 mm | SUM1350 mm |
| 119. | 167717A1 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1350.00 mm | SUM |
| 122. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 123. | 154475A1 | [1] | O-RING | SUM |
| 124. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 132. | KHJ15350 | [1] | HYDRAULIC HOSE | SUM1800 mm |
| 133. | KHJ15340 | [1] | HYDRAULIC HOSE | SUM1600 mm |
