纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (09-006-00[01]) - SELF-DETACHING COUNTERWEIGHT SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
670 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 19. | KUB0158 | [2] | LINK | SUM |
| 20. | KUB0159 | [2] | PLATE | SUM |
| 21. | 152718A1 | [4] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 23. | KUB0179 | [1] | SPACER | SUM |
| 26. | KUB0165 | [2] | PULLEY | SUM |
| 27. | KUB0180 | [2] | BUSHING | SUM |
| 28. | KUB0166 | [1] | PIN | SUM |
| 29. | KUB0160 | [2] | PLATE | SUM |
| 30. | KUB0170 | [1] | SPACER | SUM |
| 31. | KUB0171 | [2] | SPACER | SUM |
| 32. | KUB0178 | [1] | ROD,THREADED | SUMROD, THREADED |
| 33. | 829-1412 | [2] | NUT,M12, Cl 10 | CAS Superseded by part number: 337475 |
| 34. | 150811A1 | [2] | WASHER | SUMW 12 Superseded by part number: 86625255 |
| 35. | KUB0156 | [1] | HYDRAULIC CYLINDER | SUM |
| 39. | KUB0164 | [2] | WIRE ROPE | SUM |
| 40. | KUB0174 | [1] | PIN | SUM |
| 41. | KUB0176 | [2] | COLLAR | SUM |
| 42. | 102R008Y080R | [2] | BOLT | SUMM8 x 80 |
| 43. | 829-1408 | [4] | NUT,Hex, M8 x 1.25, Cl 10.9 | CAS Superseded by part number: 43362, 87778059 |
| 44. | KUB0172 | [1] | BRACKET | SUM |
| 45. | KUB0161 | [4] | PIN | SUM |
| 46. | C4E6684 | [4] | SPLIT PIN/SAFETY PIN | SUM |
| 102. | KAJ4281 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1400.00 mm | SUM |
| 103. | KWJ11030 | [1] | HYDRAULIC HOSE,9.52 mm ID x 1150.00 mm | SUM |
| 104. | 158063A1 | [1] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHR21050 |
| 105. | 150774A1 | [1] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHH12760 |
| 108. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 109. | 154475A1 | [1] | O-RING | SUM |
| 110. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
