纽荷兰零件查询(E175B) - CRAWLER EXCAVATOR TIER 3 (NA) - N7DA16301 - (5/07-) (02-76[00]) - HYD LINES, SWIVEL (YN19H00047F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
970 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | HH25X08008G5 | [1] | ELEC CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| . . | ZD12P01800 | [1] | O-RING | KOB(Part of HH25X08008G5), ID 17.80 ± 0.21 x OD 22mm, Not Shown |
| 2. | ZG33F12012 | [3] | 90 ELBOW,1 3/16"-12 UN x PF 3/4" | KOB90°, (Incls. O-Ring 237-6008) |
| . . | 237-6008 | [1] | O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro | CAS(Part of ZG33F12012), SAE No. 8-1, Not shown Superseded by part number: 128825 |
| 3. | YN03H01172P1 | [1] | ELBOW,1-3/16" - 12 ORFS x 3/4" ORB | KOB90° -- 1-3/16-12UN x 3/4 PF x 116mm Long (Incls. O-Ring ZD12P02400) |
| . . | ZD12P02400 | [1] | O-RING | KOB(Part of YN03H01172P1), ID 23.70 ± 0.24 x OD 30mm, Not Shown |
| 4. | ZD12A01800 | [4] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
