神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (06-003[03]) - INSTRUMENT PANEL HARNESS ASSEMBLY (AUX/AUX & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
834 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J21002F1 | [1] | HARNESS ASSY, INST PANEL (AUXILARY) | |
| . . | 24100J21002F2 | [1] | HARNESS ASSY, INST PANEL (AUXILIARY & BREAKS) | |
| 1. | 2416P19714 | [1] | BRACKET | KOBF1 ONLY |
| 2. | ZM66C06016 | [6] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher), F1 Only |
| 3. | YR24S00002P1 | [4] | RELAY | KOBF1 ONLY |
| 4. | 2479U2126 | [1] | WIRE HARNESS | KOBF1 ONLY |
| 5. | 2479U2132 | [1] | WIRE HARNESS | KOBF1 ONLY |
| 6. | 2479U1223F6 | [1] | SWITCH | KOBF1 ONLY |
| 7. | 2479U1223F5 | [1] | SWITCH | KOBF2 ONLY |
