神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (06-004[01]) - INSTRUMENT PANEL HARNESS ASSEMBLY 24100J20922F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1002 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J20922F1 | [1] | HARNESS ASSY, CONTROLLER | |
| 2. | YN03E01001D5 | [4] | CLIP | KOB195mm Long (7-43/64 in) -- Black |
| 3. | YN22M01005D3 | [3] | SCREW | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) Superseded by part number: ZM61C06020 |
| 5. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 6. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 7. | 2432R226D13 | [1] | CLIP | KOBClamp, Double -- ID 28 x 82mm Long |
| 14. | 2479U2122 | [1] | WIRE HARNESS | KOB |
| 15. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
