| 1. | R18T0026D2 | [1] | HOSE,12mm ID x 2700mm L | KOBID 12 x OD 22 x 2700mm |
| 2. | R18T0026D88 | [1] | HEATER HOSE,12mm ID x 4950mm L | KOBID 12 x OD 22 x 4950mm |
| 3. | YN20M01651P1 | [2] | BRACKET | KOB |
| 4. | YN20M01414D2 | [1] | BELT, TRANSMISSION | KOB1155mm Long (45-15/32 in) |
| 5. | ZC16X02000 | [4] | CLIP | KOBClamp, Hose -- Min 15 x Max 25mm |
| 6. | ZM73C10025 | [7] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| 7. | ZM73C06020 | [2] | BOLT,M6x20mm - Course Thread | KOBM06x1.0x20mm (Incls. Washer) |
| 8. | ZM73C08020 | [8] | BOLT,M8x20mm - Course Thread | KOBM08x1.25x20mm (Incls. Washer) |
| 9. | ZS18C08100 | [4] | SCREW,Hex, M8 x 100mm | KOBScrew -- M08x1.25x100mm |
| 10. | ZW16P08000 | [6] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
| 12. | YJ21M01003D1 | [1] | FLEXIBLE HOSE | SMID 22.1 x OD 27 x 1800mm |
| 13. | YN20M01427D2 | [1] | FLEXIBLE HOSE | SMID 22.1 x OD 27 x 4000mm |
| 16. | YN20M01599P1 | [1] | BRACKET | KOB |
| 17. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 19. | ZW16P10000 | [1] | WASHER | KOBID 05 x OD 10 x Th 2.0mm |
| 23. | ZM73C08025 | [2] | BOLT,M8x25mm - Course Thread | KOBM08x1.25x25mm (Incls. Washer) |
| 24. | ZC48X24014 | [3] | CLIP | KOBClamp, Double -- Ø24x85mm Long |
| 25. | PY01P01043D4 | [15] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long |
| 27. | YN20M00113F1 | [1] | AIR CONDITIONER | KOBAssembly -- See Figure 1.073 Superseded by part number: YN20M00140F1 |
| 30. | YN20M01468P1 | [1] | PANEL | SM Superseded by part number: YN20M01468P4 |
| 32. | YX91V00001F1 | [1] | COMPRESSOR,W/ Pulley | KOBSee Figure 1.075 |
| . . | YX91V00001F1R | [1] | REMAN-COMPRESSOR,W/ Pulley | KOBE215B TIER 3 (1/07-) |
| . . | YX91V00001F1C | [1] | CORE-COMPRESSOR | KOBReturn Number |
| 33. | YX20M01029F2 | [1] | PULLEY ASSY. | KOB Superseded by part number: YX20M01029F4 |
| 34. | YN20M01675P1 | [1] | CONDENSER | SM |
| 35. | YN96V00026F1 | [1] | Air Dryer Assembly -- See Figure 1.074 | |
| 39. | YN50V01015P3 | [1] | CAB FILTER | SMElement, Air-conditioner -- 201x187x17mm Superseded by part number: YN50V01015P3P |
| 40. | YN52S00044P1 | [1] | SENSOR | SMSunshine |
| 49. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 50. | YM20M01030P1 | [1] | HYD CONNECTOR | KOBM18x1.50mm -- Clamp on Hose |
| 54. | YN20M01514P1 | [1] | GASKET | SMGrommet |
| 55. | YN20M01676P1 | [1] | GASKET | SMGrommet |
| 56. | ZS18C06055 | [4] | SCREW,Hex, M6 x 55mm | KOBM06x1.0x55mm |
| 57. | ZW16P06000 | [4] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 58. | 2418Z1333D13 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 100mm Length | KOBProtective Plastic |
| 60. | ZC46X29011 | [1] | CLIP | KOBClamp, Single Line -- ID 29 x 48mm Long |
| 61. | YN20M01650P1 | [1] | HYD CONNECTOR | KOB1/2"NPTF - 3/8" Gas x 40mm Long Superseded by part number: 71460090 |
| 62. | YN20M01649P1 | [1] | HYD CONNECTOR | KOB3/8" Gas x 42.5mm Long Beaded -- Clamp on Hose Superseded by part number: 72203928 |
| 63. | ZN18C06005 | [4] | NUT | KOBM06x1.0mm |
