纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (1.084[00]) - HARNESS ASSEMBLY, UPPER PLATE, FLOOR (YN13E00103F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
810 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN13E01437P2 | [1] | WIRE HARNESS | KOB Superseded by part number: YN13E01437P3 |
| 2. | PY01P01043D3 | [33] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 3. | YN13E01375P1 | [13] | CLIP,M8 x 8.20mm Shank | KOBAnchor Wire Ties |
| 4. | LC13E01186P1 | [1] | HARNESS | KOBWiring -- 780mm Long (30-45/64 in) |
| 5. | ZW26X08000 | [1] | LOCK WASHER | KOBID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 6. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 7. | PY01P01043D8 | [3] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 9. | LE13E01005P1 | [1] | CABLE,100mm L | KOB100mm Long (3-15/16 in) |
| 10. | ZW16P08000 | [1] | WASHER | KOBID 08 x OD 17 x Th 1.6mm |
