神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (05-007) - INSTRUMENT PANEL ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
191 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J20746F5 | [1] | PANEL INSTAL ASSY (W/O RADIO) (F5 ONLY) | |
| . . | 24100J20746F6 | [1] | PANEL INSTAL ASSY (W/ RADIO) (F6 ONLY) | |
| 1. | YN52S00009P1 | [1] | POTENTIOMETER | KOB |
| 3. | YN50S00002F1 | [1] | IGNITION SWITCH | KOBIGNITION Superseded by part number: YN50S00026F1 |
| 3-1. | 2420Z1030D2 | [1] | KIT | KOB(YN50S00002S001) Superseded by part number: PM50S01001P1 |
| 3-4. | YN50S00002S004 | [1] | TOGGLE SWITCH | KOBSWITCH |
| 5. | 2479U1348F2 | [1] | SWITCH | KOBK.P.S.S. (MODE SELECT) |
| 6. | 2479U1278F2 | [1] | SWITCH | KOBWIPER |
| 7. | 2479U1578F1 | [1] | SWITCH | KOBRR WORK LAMP |
| 8. | 2479U1190F9 | [1] | SWITCH | KOBSWING FLASHERS |
| 9. | 2479U1190F7 | [1] | SWITCH | KOBAUTO ACCEL/DECEL |
| 10. | 2479U1191F1 | [1] | SWITCH | KOBBUZZER STOP |
| 12. | 2479U1224F4 | [4] | SWITCH | KOBTRAVEL SPEED |
| 13. | YN17M01032P1 | [4] | CAP | KOB |
| 15. | YN81S00001P1 | [1] | SOCKET | KOB |
| 16. | 2421R180F1 | [1] | CIGARETTE LIGHTER | KOB Superseded by part number: YN81S00003P1 |
| 18. | 2420R429D11 | [1] | GROMMET | KOB |
| 19. | ZM66C06016 | [3] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 20. | ZM46C06016 | [4] | SCREW | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 21. | 2447Z156D2 | [1] | BUZZER | KOB |
| 22. | YN03M01210P1 | [1] | PLATE | KOB |
| 23. | ZM46C04012 | [2] | SCREW | KOBM04x0.7x12mm (Incls. Washer & Lockwasher) |
| 24. | YN22M01013P1 | [1] | LABEL | KOB |
| 25. | 2414N5536 | [1] | COVER | KOB(F5 ONLY) |
| 27. | YN17M01038P1 | [1] | PLATE | KOB |
| 28. | YN54S00001F2 | [2] | SPEAKER | KOB(F6 ONLY) Superseded by part number: GG54S00001F1 |
| 29. | ZM46C04016 | [8] | SCREW | KOBM04x0.7x16mm (Incls. Washer & Lockwasher) |
| 30. | 2479U1190F15 | [1] | SWITCH | KOBDOZER |
| 31. | YN17M01029P1 | [2] | PLATE | KOB |
| 32. | 2479U1626 | [1] | KIT | KOBAM/FM (F6 ONLY) |
| 33. | 2416P20426D1 | [1] | BRACKET | KOB(F6 ONLY) |
| 34. | 2416P20426D2 | [1] | BRACKET | KOB(F6 ONLY) |
| 35. | ZS31C05016 | [4] | BOLT,Phillips Drive, Pan HD, M5 x 16mm | KOBM05x0.8x16mm, F6 Only |
| 36. | ZW22X05000 | [4] | LOCK WASHER | KOBID 05 x OD 09.2 x Th 1.3mm, (F6 Only) |
| 37. | ZS18C08014 | [4] | SCREW,Hex, M8 x 14mm | KOBM08x1.25x14mm, (F6 Only) |
| 38. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm, (F6 Only) Superseded by part number: 83990583 |
| 40. | 2406R544 | [1] | | |
| 41. | 2432T6026 | [1] | LABEL | KOBDOZER |
| 42. | 2432T6815 | [1] | LABEL | KOBDOZER |
| 43. | 2479R2321 | [1] | WIRE HARNESS | KOBWIRING (F6 ONLY) |
| 44. | 2479R656 | [1] | WIRE HARNESS | KOB(F6 ONLY) |
| 45. | 2420R584 | [6] | FASTENER | KOB |
| 46. | 2420Z1229D1 | [2] | SCREW | KOBMACHINE (M4x16MM) |
| 47. | 2418Z726D4 | [2] | LOCK WASHER | KOBID 04 x OD 7.6 x Th 1.0mm |
| 48. | 2414N5531 | [1] | COVER | KOB(F6 ONLY) |
| 49. | YN17M01037P1 | [2] | PLATE | KOB(F5 ONLY) |
| 50. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm, (F6 Only) |
| 51. | 24100J17421F1 | [1] | INSTALLER JIG | KOB |
| 51-1. | 2489U276F6 | [1] | GAUGE | KOBCLUSTER (SEE FIGURE 05-010) Superseded by part number: YN59S00027F1 |
| 51-2. | 2416N7162 | [1] | U-BRACKET | KOB |
| 51-3. | 2414N5616 | [1] | COVER | KOB |
| 51-4. | 2414N5617 | [1] | COVER | KOB |
| 51-5. | 2420R1091D3 | [4] | SCREW | KOB |
| 51-6. | 2420Z1323D2 | [4] | SCREW | KOB |
| 52. | 2456R445 | [1] | LAMP,24V, 3W | KOBWARNING,TEMPATURE |
| 53. | ZS23C08025 | [4] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 54. | ZW26K08000 | [4] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 59. | 2432T6130 | [1] | LABEL | KOB |
| 63. | LC77SU0001P1 | [1] | CONVERTER | KOB |
