| 0. | YN01V00153F1 | [1] | HYDRAULIC CYLINDER | KOBBucket |
| A1. | YN12B02218P1 | [1] | PIN,80mm OD x 252mm L | KOBOD 80 x 252mm Long |
| A2. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBM16x2.0x140mm |
| A3. | ZN18C16013 | [2] | NUT | KOBM16x2.0mm |
| A4. | YN12B01601D1 | [2] | SHIM,82mm ID x 140mm OD x 2mm Thk | KOBID 82 x OD 140 x Th 2.0mm |
| A5. | YN12B01122D1 | [1] | SHIM,82mm ID x 140mm OD x 0.5mm Thk | KOBID 82 x OD 140 x Th 0.5mm |
| A6. | YN12B01122D2 | [1] | SHIM,82mm ID x 140mm OD x 0.9mm Thk | KOBID 82 x OD 140 x Th 0.9mm |
| A7. | YN12B01122D3 | [1] | SHIM,82mm ID x 140mm OD x 1.6mm Thk | KOBID 82 x OD 140 x Th 1.6mm |
| B1. | YN43H01572P1 | [1] | TUBE,27.2 mm OD x 1262.5, 65 mm Length | KOB |
| B2. | YX42H01074P2 | [1] | BAND | KOB |
| B3. | YN43H01639P1 | [1] | BAND | KOB |
| B4. | YN43H01097P1 | [1] | CLAMP | KOBSingle -- 58x30x38mm (Ø28mm) |
| B5. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| B6. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90°x1/8" PT |
| B7. | ZD12P02600 | [1] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| B8. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| B9. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| B10. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| B11. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm |
| B12. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B13. | ZW16H10000 | [1] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| C1. | ZX50H12135 | [1] | HOSE | KOB1350mm Long (53-9/64 in) |
| C2. | YN43H01576D1 | [1] | HOSE | KOB1400mm Long (55-7/64 in) |
| C3. | ZE13X16000 | [2] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| C4. | ZS28C12040 | [4] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| C5. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| C6. | ZW26K12000 | [4] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
