纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (3.009[00]) - ARM, 2.94M (9FT 8IN) (YN12B00821F1) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
781 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-1. | NSS | [1] | NOT SERVICED SEPARATELY | CONARM |
| 1-2. | YN12B02285P1 | [2] | BUSHING,89mm ID x 130mm OD x 100mm L | KOB |
| 1-3. | YN12B02102P1 | [2] | BUSHING,70mm ID x 85mm OD x 69mm L | KOB |
| 1-4. | YN12B02137P1 | [2] | BUSHING,90mm ID x 105mm OD x 89mm L | KOB |
| 1-5. | YN12B01943P1 | [2] | BUSHING,80mm ID x 95mm OD x 89mm L | KOB |
| 2. | YN12B00742P1 | [1] | ARM | |
| 2-1. | YN12B02417P1 | [2] | BLOCK | KOBBLOCK,TAPPED |
| 2-2. | YN12B02026P1 | [4] | BLOCK | KOBBLOCK,TAPPED |
| 3. | YN12B00786P1 | [1] | ARM | |
| 4-1. | 2416T4194 | [1] | BLOCK | KOBTAPPED |
