纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (5.015-01[00]) - VALVE ASSEMBLY, SOLENOID (LC35V00004F1, F2 & F3) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
691 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC35V00004F1 | [1] | SOLENOID VALVE | KOBAssembly |
| . . | LC35V00004F2 | [1] | SOLENOID VALVE | KOBAssembly |
| . . | LC35V00004F3 | [1] | HYDRAULIC VALVE | SMAssembly, Solenoid |
| 1. | NA | [2] | NOT SERVICED | FORSpool -- (F1 Only) |
| 2. | 2436U2802S3 | [2] | SPRING | KOB |
| 3. | LC35V00004S005 | [2] | VALVE | KOBAssembly, Solenoid -- (F1 Only) |
| 7. | LC35V00004S007 | [2] | PLUG | KOB1/4" PF -- (F3 Only) |
| 8. | LC35V00004S008 | [4] | SCREW | KOBM05x0.8x10mm |
| 9. | EZ30V00001S037 | [2] | SCREW | KOB(F1 Only) |
| 10. | ZD11P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20.6mm |
| 11. | ZD12P01100 | [2] | O-RING | KOBID 10.80 ± 0.18 x OD 15mm -- (F3 Only) |
| 13. | YR35V00009S022 | [2] | SOLENOID VALVE | KOBValve Assembly, Solenoid -- (F2, F3 Only) |
| 15. | YN30V00080S023 | [2] | SCREW | KOB#2x4.8mm -- (F2, F3 Only) |
