| A3. | YN17M01334F1 | [1] | GUARD | SMAssembly, Incls. Refs. A3-1 - A3-7 |
| A3-1. | YN17M01299F1 | [1] | COVER ASSY | KOBIncls. Refs. A3-1A - A3-1C |
| A3-1A. | YN17M01181P2 | [1] | COVER | KOB |
| A3-1B. | YN17M01300P1 | [1] | DATA PLAQUE | SMDecal -- High/Low Position |
| A3-1C. | YN17M01312P1 | [1] | DATA PLAQUE | SMDecal -- Key Switch Position |
| A3-2. | YN52S00032P1 | [1] | POTENTIOMETER | KOBCab Fan Control Switch - High/Low, Includes Refs. A3-2A & A3-2B Superseded by part number: YN52S00032P2 |
| A3-2A. | YN52S00032S001 | [1] | POTENTIOMETER | KOBFan Control Switch Superseded by part number: YN52S00032P2 |
| A3-2B. | YN52S00032S002 | [1] | KNOB | KOBFan Control Switch Superseded by part number: YN52S00032S003 |
| A3-3. | YN17M01273P1 | [1] | BRACKET | SM |
| A3-4. | YN50S00026F2 | [1] | SWITCH | KOBIgnition -- (Incls. Keys PM50S01001P1), Incls. Refs. A3-4A - A3-4D |
| A3-4A. | PM50S01001P1 | [2] | IGNITION KEY | KOBKEY, LOCK (Part of YN50S00026F2), Set of 2 Keys |
| A3-4B. | YN50S00002S004 | [1] | TOGGLE SWITCH | KOB |
| A3-4C. | YN50S00002S005 | [1] | WASHER | KOBWave |
| A3-4D. | YN50S00002S002 | [1] | NUT | KOB |
| A3-5. | ZW16P05000 | [2] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| A3-6. | YN17M01262P1 | [2] | SCREW,Phillips Drive, Pan HD, M5 x 10mm | SMM05x10mm Self-Taper |
| A3-7. | ZM41C04012 | [2] | BOLT | KOBM04x0.7x12mm (Incls. Washer & Lockwasher) |
| A4. | YN17M01316F1 | [1] | GUARD | SMAssembly, Incls. Refs. A4-1 & A4-2, Used from date 02/04/2006 - 05/14/2007 Superseded by part number: YN17M01316F2 |
| A4. | YN17M01316F2 | [1] | GUARD | SMAssembly, Incls. Refs. A4-1 & A4-2, Used after date 05/14/2007 - Up |
| A4-1. | YN17M01285F1 | [1] | COVER ASSY | KOBIncls. Refs. A4-1A - A4-1J, (F1) Superseded by part number: YN17M01285F2 |
| A4-1. | YN17M01285F2 | [1] | COVER ASSY | KOBCover Assembly, Incls. Refs. A4-1A - A4-1M, (F2) |
| A4-1A. | YN17M01182P1 | [1] | COVER | KOB(F1 & F2) Superseded by part number: YN17M01316F2 |
| A4-1B. | YN17M01183P1 | [1] | COVER | KOB(F1) Superseded by part number: YN17M01183P2 |
| A4-1B. | YN17M01183P2 | [1] | COVER | KOBCover, (F2) |
| A4-1C. | YN17M01264P1 | [4] | SCREW | SMM06x15mm Self-Taper, (F1 & F2) |
| A4-1D. | YN17M01266P1 | [4] | WASHER | SMID 06.4 x OD 11.5 x Th 1.6mm, (F1 & F2) |
| A4-1H. | YN17M01302P1 | [3] | STAPLE | SMClip, (F1 & F2) |
| A4-1J. | YN17M01305P1 | [3] | SCREW | SMM03x08mm Long Self-Taper, (F1 & F2) |
| A4-1K. | YN17M01303P1 | [2] | COLLAR | KOBCollar, (F2), Not Shown |
| A4-1M. | YN17M01296P1 | [1] | HOSE CLIP | SM(F2), Not Shown |
| A4-2. | YN81S00003P1 | [1] | CIGARETTE LIGHTER | SM |
| A22. | ZM66C06016 | [19] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| A26. | ZM41C05016 | [4] | BOLT | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| A29. | YN17M01267P1 | [2] | CAP | KOB |
| A31. | YN17M01269P1 | [1] | BRACKET | SM |
| A32. | YN17M01270P1 | [1] | BRACKET | SM |
| A34. | YN17M01275P1 | [1] | BRACKET | SM |
| A35. | YN17M01277P1 | [1] | BRACKET | SM |
| A39. | YN17M01283P1 | [1] | BOLT | SMM06x1.0x30mm (Incls. Washer & Lockwasher) |
| A40. | YN17M01284P2 | [2] | BOLT | SMM06x1.0x16mm (Incls. Washer & Lockwasher) |
| B1. | YN50S00040D1 | [1] | LIGHT SWITCH | SMWork Light |
| B2. | YN50S00040DD | [1] | TOGGLE SWITCH | SMDouble Flow (Nibbler & Breaker) |
| B3. | YN50S00040D5 | [1] | SWITCH | KOBHeavy Lift |
| B4. | YN50S00040DB | [1] | SWITCH | KOBIndependent Travel |
| B5. | YN17M01282P1 | [1] | CAP | KOBPlug, 43x25x27mm |
