| . . | 24100J16957F3 | [1] | ARM ASSY 3.06M (AUXILIARY) | |
| 2. | 2438U1949F1 | [1] | CYLINDER | KOBBUCKET |
| 3. | 2406N1736F1 | [1] | LINK CONROD | KOB |
| 3-6. | 2405T1885 | [2] | BUSHING | KOB |
| 3-7. | 2405P725 | [2] | BUSHING | KOB |
| 4. | 2406P5564 | [1] | LINK | KOBRH |
| 5. | 2406P5565 | [1] | LINK | KOBLH |
| 7. | 2418P10046D2 | [1] | RIGID TUBE | KOB145mm Long (5-45/64 in) |
| 8. | 2418P31929 | [1] | TUBE | KOB |
| 9. | 2444R1169D11 | [2] | HOSE | KOB(1750mm Long (68-57/64 in)) (w/ Guard) |
| 10. | 2419P4116 | [2] | PIN | KOB |
| 11. | 2419P4115 | [1] | PIN | KOB |
| 12. | 2419P4114 | [1] | PIN | KOB |
| 13. | 2419P4113 | [1] | PIN | KOB |
| 14. | 2419P4046D3 | [1] | PIN | KOB |
| 15. | 2445R138D4 | [2] | SEAL,65mm ID x 80mm OD x 4mm Thk | KOB |
| 16. | 2445R138D7 | [2] | SEAL,80mm ID x 95mm OD x 4mm Thk | KOBDust -- ID 80 x OD 95 x Th 4mm |
| 17. | 2445R138D6 | [4] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 18. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 19. | 2445R220D3 | [4] | SEAL,70mm ID x 85mm OD x 5mm Thk | KOBDust -- ID 70 x OD 85 x Th 5mm |
| 20. | 2432T1333 | [1] | CLAMP | KOBSingle Block -- 50x30x25mm Superseded by part number: YW43H01049P1 |
| 21. | 2420T4327D7 | [2] | SCREW,M14 x 2 x 130mm | KOB(M14 x 130mm) |
| 22. | 2420T4330D10 | [1] | SCREW,M16 x 2 x 140mm | KOBM16x2.0x140mm Superseded by part number: ZS18C16140 |
| 23. | ZS13C10060 | [8] | SCREW | KOBM10x1.50x60mm Superseded by part number: ZS18C10060 |
| 24. | ZS13C10050 | [1] | SCREW | KOBM10x1.50x50mm Superseded by part number: ZS18C10050 |
| 25. | ZN13C14011 | [6] | NUT | KOBM14x2.0mm Superseded by part number: ZN18C14011 |
| 26. | ZN13C16013 | [2] | NUT | KOBM16x2.0mm |
| 27. | ZW22X10000 | [9] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 28. | ZG91U02000 | [2] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 29. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 30. | B16T0442D3 | [1] | SHIM,150mm OD x 82mm ID x 1.2mm Thk | KOBID 82 x OD 150 x Th 1.2mm |
| 31. | B16T0442D4 | [1] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 32. | B16T0442D6 | [1] | SHIM,150mm OD x 82mm ID x 2.3mm Thk | KOBID 82 x OD 150 x Th 2.3mm |
| 33. | B16T0442D1 | [3] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| 34. | B16T0442D2 | [3] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 35. | B16T0442D5 | [3] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOBID 72 x OD 130 x Th 2.3mm |
| 36. | 2418T23987D2 | [2] | RING | KOBRetaining -- ID 105 ± 1.0 x OD 110 x Th 12mm |
| 37. | 2419T6002D6 | [2] | PIN,16mm OD x 102mm L | KOBOD 16 x 102mm Long |
| 38. | 2418T4037D2 | [1] | SHIM,67mm ID x 110mm OD x 1.2mm thk | KOBID 67x OD 110 x Th 1.2mm |
| 39. | 2418T4037D5 | [1] | SHIM,67mm ID x 110mm OD x 1.6mm thk | KOBID 67x OD 110 x Th 1.6mm |
| 40. | 2418T4037D1 | [1] | SHIM,67mm ID x 110mm OD x 2.3mm thk | KOBID 67x OD 110 x Th 2.3mm |
| 41. | 2418T4037D3 | [1] | SHIM,67mm ID x 110mm OD x 0.9mm Thk | KOBID 67x OD 110 x Th 0.9mm |
| 42. | B16T0442D88 | [1] | SHIM,100mm OD x 67mm ID x 0.5mm Thk | KOBID 67 x OD 100 x Th 0.5mm |
| 43. | 2420T4327D5 | [1] | SCREW,M14 x 2 x 115mm | KOB(M14 x 115mm) |
| 44. | B16T0442D44 | [4] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOBID 72 x OD 130 x Th 0.9mm |
| 45. | B16T0442D57 | [4] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOBID 72 x OD 130 x Th 0.5mm |
| 46. | B16T0442D39 | [1] | SHIM,82mm ID x 150mm OD x 0.9mm Thk | KOBID 82 x OD 150 x Th 0.9mm |
| 47. | B16T0442D52 | [1] | SHIM,82mm ID x 100mm OD x 0.5mm Thk | KOBID 82 x OD 150 x Th 0.5mm |
| 55. | 2411J5093D3F1 | [1] | ARM, LONG | |
| 55-20. | 2405P726 | [2] | BUSHING | KOB |
| 55-21. | 2405T1887 | [2] | BUSHING | KOB |
| 55-22. | 2405T1888 | [2] | BUSHING | KOB |
| 101. | 2418P34122 | [1] | TUBE | KOB |
| 102. | 2418P34123 | [1] | TUBE | KOB |
| 103. | 2444Z2878D8 | [2] | FLEXIBLE HOSE | KOB(L=1800mm) (w/Guard) |
| 104. | 24100P1006F1 | [2] | VALVE | KOB Superseded by part number: 24100P1006F2 |
| 104-1. | 2436P230 | [1] | VALVE BODY | KOB |
| 104-2. | 2436T304 | [1] | VALVE | KOB |
| 104-3. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| 104-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 104-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 104-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 104-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 104-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 104-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 104-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 104-11. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 105. | 2444P1744D2 | [2] | CONNECTION | KOB(No O-Ring supplied) |
| 106. | ZA23F28012 | [2] | HYD CONNECTOR | KOB |
| 107. | 2420T4404 | [2] | PLUG | KOB1-1/16" - 12 UNC |
| 108. | ZD12P02400 | [4] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 109. | 2444T2158 | [1] | HYD CONNECTOR | KOBIncls. 2444T2159 Connector, ZF93N28000 Nut, & ZF93S28000 Sleeve |
| 110. | ZC26X28014 | [2] | CLAMP | KOBSingle Line -- 75x37x38mm (Ø28mm) |
| 111. | ZS13C12050 | [2] | SCREW | KOBM12x1.75x50mm Superseded by part number: ZS18C12050 |
| 112. | ZS13C08025 | [8] | SCREW | KOBM08x1.25x25mm Superseded by part number: ZS18C08025, 77276313 |
| 113. | ZW22X12000 | [2] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 114. | ZW22X08000 | [8] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
