神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (08-007) - BUCKET ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
250 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N8104F2 | [1] | BUCKET ASSY, STD | |
| 2. | B12N0006F1 | [4] | TOOTH | KOBTOOTH ASSY |
| 2-1. | NSS | [1] | NOT SOLD SEPARAT | CONTOOTH |
| 2-2. | NSS | [1] | NOT SOLD SEPARAT | CONPIN, LOCKING |
| 2-3. | NSS | [1] | NOT SOLD SEPARAT | CONPIN-LOCK, RUBBER |
| 3. | 2412N278D11 | [1] | BLADE | KOBCUTTER, SIDE |
| 4. | 2412N278D21 | [1] | BLADE | KOBCUTTER, SIDE |
| 5. | ZS13C20050 | [8] | SCREW | KOBCAPSCREW |
| 6. | ZN13C20016 | [8] | NUT | KOBNUT |
| 7. | 2405T1886 | [1] | BUSHING | KOB |
| 8. | 2445Z1570 | [4] | O-RING,9mm Thk x 125mm ID, Cl 5, 75 Duro | KOBID 125 ± 0.40 x OD 143mm |
| 9. | ZS23C14035 | [3] | SCREW,Hex Socket Head, M14 x 35mm | KOBM14x2.0x35mm |
| 10. | ZW22K14000 | [3] | LOCK WASHER | KOBID 14.2 x OD 21.8 x Th 3.5mm |
| 11. | 2419T3772 | [1] | PIN | KOB |
| 12. | 2418T12260D2 | [3] | SHIM | KOB3.2 |
| 13. | 2418T12260D1 | [21] | SHIM | KOB1.0 |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONBUCKET |
| 14-1. | NSS | [1] | NOT SOLD SEPARAT | CONEDGE, CUTTING |
| 14-2. | NSS | [1] | NOT SOLD SEPARAT | CONADAPTER |
