沃尔沃零件查询5.0FLPMDA; 5.8FLPMDACooling SystemSeawater Pump PartsEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
523 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3852398
|
[1] |
Water pump
|
Replaced by 3851623
|
| 2. |
3854287
|
[1] |
Water pump kit
|
|
| 3. |
3854286
|
[1] |
Impeller
|
Contents of water pump repair kit
|
| 4. |
3854293
|
[1] |
O-ring, housing
|
Contents of water pump repair kit
|
| 5. |
3854296
|
[1] |
Gasket, plate to body
|
Contents of water pump repair kit
|
| 6. |
3854297
|
[3] |
Screw, body to hsg
|
Contents of water pump repair kit
|
| 7. |
3854292
|
[3] |
Tab washer, screw to hsg
|
Contents of water pump repair kit
|
| 8. |
3854289
|
[1] |
Washer, cam screw
|
Contents of water pump repair kit
|
| 9. |
3854291
|
[1] |
Cam, impeller
|
|
| 10. |
3854288
|
[1] |
Housing
|
|
| 11. |
3854290
|
[1] |
Screw, cam
|
|
| 12. |
3854295
|
[1] |
Plate
|
Contents of water pump repair kit
|
| 13. |
3854294
|
[1] |
Woodruff key, impeller
|
|
