沃尔沃零件查询5.0FLPMDA 5.8FLPMDAEngineCrankcaseEPC Volvo Penta Parts catalog_沃尔沃遍达Volvo Penta_工程机械

Pos.	Part No	Qty	Parts name	Comments
1.	3850839	[1]	Base engine	Replaced by 3855164
1.	3855164	[1]	Base engine
2.	3853007	[4]	Guide sleeve, cylinder head to block
3.	3852650	[6]	Cap plug, core hole
4.	3853008	[6]	Cap plug
5.	3853108	[6]	Plug, oil gallery
6.	3853008	[2]	Cap plug, oil passage
7.	3852766	[1]	Expansion plug, rear, cam, standard
7.	3853009	[1]	Cap plug, rear cam, 0.060 in. os
8.	3853076	[1]	Locating pin, adapter hsg to block
9.	3853065	[9]	Bolt, main bearing cap
10.	3853066	[1]	Stud, main bearing cap
11.	3853026	[1]	Nut, main bearing cap
12.	3853010	[1]	Cap plug, rear hole in block
13.	3852792	[1]	Crankshaft
14.	3853900	[1]	Piston ring kit, standard (pkg. of 2)	Contains rings for 2 pistons
14.	3853844	[1]	Piston ring kit, 0.020 in. os	Contains rings for 2 pistons.
14.	3853879	[1]	Piston ring kit, 0.030 in. os	Contains rings for 2 pistons.
14.	3853885	[1]	Piston ring kit, 0.040 in. os	Contains rings for 2 pistons.
15.	3857020	[8]	Piston, standard
15.	3857021	[1]	Piston, 0.020 in. os
15.	3857022	[1]	Piston, 0.030 in. os
15.	3857023	[1]	Piston, 0.040 in. os
16.	3852773	[8]	Gudgeon pin, piston, standard
17.	3852775	[16]	Bearing, connecting rod, standard
17.	3853041	[1]	Bearing, connecting rod, 0.010 in. U.S.
17.	3853042	[1]	Bearing, connecting rod, 0.020 in. U.S.
17.	3853043	[1]	Bearing, connecting rod, 0.030 in. U.S.
17.	3853044	[1]	Bearing, connecting rod, 0.040 in. U.S.
18.	3853901	[8]	Connecting rod
19.	3852777	[16]	Nut, connecting rod
20.	3852776	[16]	Bolt, connecting rod
21.	3852778	[1]	Camshaft
22.	3852797	[8]	Bearing, upper, standard
22.	3853047	[1]	Bearing, main, upper, 0.010 in. U.S.
22.	3853048	[1]	Bearing, main, upper; 0.020 in. U.S.
22.	3853049	[1]	Bearing, main, upper, 0.030 in. U.S.
23.	3852798	[8]	Bearing, lower, standard
23.	3853052	[1]	Bearing, main, lower, 0.010 in. U.S.
23.	3853053	[1]	Bearing, main, lower, 0.020 in. U.S.
23.	3853054	[1]	Bearing, main, lower, 0.030 in. U.S.
24.	3852800	[2]	Bearing, center, lower, standard
24.	3853062	[1]	Bearing, main, center, lower, 0.010 in. U.S.
24.	3853063	[1]	Bearing, main, center, lower, 0.020 in. U.S.
24.	3853064	[1]	Bearing, main, center, lower, 0.030 in. U.S.
25.	3852799	[2]	Bearing, center, upper, standard
25.	3853057	[1]	Bearing, main, center, upper, 0.010 in. U.S.
25.	3853058	[1]	Bearing, main, center, upper, 0.020 in. U.S.
25.	3853059	[1]	Bearing, main, center, upper 0.030 in. U.S.
26.	3852781	[1]	Bearing, camshaft, center
26.	3853019	[1]	Bearing, center, 0.015 in. U.S.
27.	3852782	[1]	Bearing, camshaft, rear
27.	3853020	[1]	Bearing, rear, 0.015 in. U.S.
28.	3852783	[1]	Bearing, camshaft
28.	3853022	[1]	Bearing, front intermediate, 0.015 in. U.S.
29.	3852784	[1]	Bearing, camshaft, rear intermediate
29.	3853023	[1]	Bearing, rear intermed., 0.015 in. U.S.
30.	3852780	[1]	Bearing, camshaft, front
30.	3853018	[1]	Bearing, front, 0.015 in. U.S.
31.	3852791	[1]	Bolt, camshaft sprocket
32.	3853903	[1]	Chain	Double roller, Use link belt chain set 3856737 for service of chain and gears
32.	3856737	[1]	Chain, Set	Link belt
32.				Link belt, Not sold separately
32.	3852794	[1]	Sprocket, crankshaft	Double roller, Use link belt chain set 3856737 for service of chain and gears
32.	3852785	[1]	Sprocket, camshaft	Double roller, Use link belt chain set 3856737 for service of chain and gears
33.	3852795	[1]	Woodruff key, sprocket
34.	3852790	[1]	Washer, camshaft sprocket
35.	3853075	[1]	Washer
36.	3852786	[1]	Locating pin, camshaft sprocket
37.	3852805	[1]	Seal, crankshaft, rear
38.	3853905	[1]	Oscillation damper, crankshaft	3 holes
39.	3853021	[1]	Bolt, crankshaft damper
40.	3852673	[1]	Eccentric, fuel pump, outer
41.	3852789	[1]	Eccentric, fuel pump, inner
42.	3853893	[1]	Timing gear casing
43.	3852788	[2]	Bolt, thrust plate
44.	3852787	[1]	Plate, camshaft thrust, standard
44.	3853024	[1]	Plate, 0.002 in. os, camshaft thrust
44.	3853025	[1]	Plate, 0.004 in. os, camshaft thrust
45.	3852768	[1]	Indicator, timing
46.	3853035	[1]	Insert, oil filter
47.	3853953	[1]	Flywheel
48.	3852804	[1]	Gear ring, flywheel
49.	3853827	[1]	Seal, front cover
50.	3853078	[1]	Clamp, distributor
51.	3853077	[1]	Screw, clamp, distributor
52.	3854496	[6]	Washer, dampener to flywheel	290 DP
52.	3854497	[6]	Lock nut, dampener to flywheel	290 DP
53.	3853273	[6]	Nut
54.	3853862	[1]	Rubber coupling, flywheel	SX, DP-S
55.	3853274	[6]	Stud, flywheel & coupler to crankshaft	SX, DP-S
56.	3854495	[6]	Stud, shoulder, dampener to flywheel	290 DP
57.	835779	[1]	Oil filter
58.	3852421	[5]	Screw, flywheel cover to hsg
58.	3853003	[1]	Cover
59.	3855088	[1]	V-belt pulley, crankshaft
60.	3855088	[1]	V-belt pulley	3 holes
61.	3853800	[1]	Oil pressure sensor, dil pressure
61.	834921	[1]	Oil pressure sensor, oil psi, dual station
62.	3852767	[1]	Gasket, front cover
63.	3853011	[1]	Bolt, front cover, 2 in
63.	3853012	[1]	Bolt, front cover,1-314 in
63.	3853013	[1]	Bolt, front cover, 2-1/4 in
63.	3853014	[1]	Bolt, front cover, 2-1/2 in
64.	3850520	[1]	Oscillation damper	290 DP
65.	3853557	[3]	Flange screw, pulley to crankshaft
66.	3852712	[1]	Nipple, oil pressure sending unit
67.	3852711	[1]	Fitting, oil pressure sending unit
68.	3850412	[1]	Bushing, pilot, crankshaft
69.	3855532	[8]	Screw, flywheel to crankshaft	290 DP
70.	3854494	[2]	Drain cock
