纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (6.008[00]) - STEP INSTALLATION (YN41CU0002F1, F2 & F3) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
797 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN41CU0002F1 | [1] | STEP | KOBInstallation Superseded by part number: ZW26X12000, ZS18C12050, YN41CU0003P1, ZN18C12010 |
| . . | YN41CU0002F2 | [1] | STEP | KOBStep Installation Superseded by part number: ZN18C12010, ZW26X12000, ZS18C12050, YN41CU0004P1 |
| . . | YN41CU0002F3 | [1] | STEP | KOBInstallation Superseded by part number: ZS18C12050, ZW26X12000, ZN18C12010, YN41CU0005P1 |
| 1. | YN41CU0003P1 | [4] | STEP | KOB(F1 Only), Incls. Refs. 3, 4 & 5 |
| 2. | YN41CU0004P1 | [4] | STEP | KOB(F2 Only), Incls. Refs. 3, 4 & 5 |
| 3. | ZS18C12050 | [8] | SCREW,Hex, M12 x 50mm | KOBM12x1.75x50mm |
| 4. | ZW26X12000 | [8] | WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 5. | ZN18C12010 | [8] | NUT | KOBM12x1.75mm |
| 6. | YN41CU0005P1 | [4] | STEP | KOB(F3 Only), Incls. Refs. 3, 4 & 5 |
