纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (6.013[02]) - LOWER FRAME GROUP (HIGH & WIDE) (YN01FU0003F1 & YN01FU0003F2), FIGURE 2 OF 2 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
603 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ01F01059P1 | [2] | COVER | KOB |
| 2. | YN63D00003P1 | [6] | GUIDE | KOBTrack (F1 Only) Superseded by part number: YN63D00003P2 |
| 2. | YN63D00003P2 | [6] | GUIDE | KOB |
| 3. | 2422T556 | [1] | PLATE | KOB90x50x Th 06mm |
| 4. | 2418T12274 | [1] | PACKING | KOB90x50x Th 05mm |
| 5. | 2420P1580D1 | [24] | SCREW,M18 x 1.5 x 40mm | KOBScrew -- M18x1.50x40mm, (F1 Only) |
| 6. | ZM73C12025 | [8] | BOLT,M12x25mm - Course Thread | KOBM12x1.75x25mm (Incls. Washer) |
| 7. | ZS18C10014 | [2] | SCREW,Hex, M10 x 14mm | KOBM10x1.50x14mm |
| 8. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 10. | YN01FU1020P1 | [2] | STONEGUARD | KOBRock Guard (F2 Only) Superseded by part number: YN01F01096P1 |
| 11. | LQ01FU1030P1 | [2] | COVER | KOBCover |
| 12. | LQ01FU1015P1 | [4] | BOLT,M24 x 3 x 50mm | KOBM24x3.0x50mm Long |
| 13. | LQ01FU1016P1 | [2] | BOLT,M24 x 3 x 110mm | KOBM24x3.0x110mm Long |
| 14. | ZN23C24027 | [2] | SLOTTED NUT | KOBM24x3.0mm |
| 15. | ZP15D05045 | [2] | PIN | KOB Superseded by part number: ZP15D05080 |
