神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (11-004) - ELEMENT KIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
533 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24043R43F1 | [1] | ELEMENT KIT | |
| 1. | YN02PU1010P1 | [1] | ELEMENT | KOBFUEL SEPARATOR Superseded by part number: 84557708 |
| 2. | YN50VU0001D3 | [1] | ELEMENT | KOBFUEL Superseded by part number: 84557099 |
| 3. | 2421R381D26 | [1] | MANUAL, OPERATOR & MAINT. | |
| 4. | 2445Z1570 | [4] | O-RING,9mm Thk x 125mm ID, Cl 5, 75 Duro | KOBID 125 ± 0.40 x OD 143mm |
| 5. | 2421R406 | [1] | MANUAL, ENG. PARTS | |
| 6. | 2421R407 | [1] | MANUAL, ENG. OPERATOR | |
| 7. | 2421R418D13 | [1] | MANUAL, PARTS | |
| 8. | YR50V00006F3 | [1] | ELEMENT | KOB |
| 8-1. | YR50V00004P1 | [1] | HYDRAULIC OIL FILTER | KOBHYD Superseded by part number: YR50V00004P1P |
| 8-4. | ZD11P13000 | [1] | O-RING | KOBID 129.6 ± 1.05 x OD 140mm |
| 9. | YN50VU0001D9 | [1] | ENGINE OIL FILTER | KOBOIL |
