神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (07-002) - IDLER ASSEMBLY 24100N10081F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
283 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N10081F1 | [2] | IDLER | KOBIncls. Refs. 1 - 14 |
| 1. | 24100N10081S001 | [1] | CYLINDER | KOBGrease |
| 2. | 24100N10081S002 | [1] | COLLAR | KOB |
| 3. | 24100N10081S003 | [1] | SPRING | KOB |
| 4. | 24100N10081S004 | [1] | BRACKET | KOB |
| 5. | 24100N10081S005 | [1] | NUT | KOB |
| 6. | 24100N10081S006 | [1] | PIN | KOBSpring |
| 7. | 24100N10081S007 | [1] | OIL SEAL | KOBSeal, Oil |
| 8. | 24100N10081S008 | [1] | O-RING | KOB |
| 9. | 24100N10081S009 | [1] | PISTON | KOB |
| 10. | 24100N10081S010 | [1] | PIN | KOB |
| 11. | 24100N10081S011 | [1] | SHAFT | KOB |
| 12. | 24100N10081S012 | [1] | PIN | KOBSpring |
| 13. | 24100N10081S013 | [2] | SCREW | KOBCapscrew |
| 14. | 24100N10081S014 | [1] | IDLER WHEEL | KOBWheel, Idler |
