| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| . . | 24100J21253F1 | [1] | HYD PIPING KIT | |
| 1. | 2444Z4658 | [2] | ||
| 2. | 2444R3169 | [2] | ||
| 3. | 2444Z4653 | [4] | ||
| 4. | 2444Z4654 | [2] | ||
| 5. | 2444R3170 | [2] | ||
| 6. | 2444R3171 | [2] | ||
| 8. | 2419P4655 | [4] | CONNECTOR | |
| 9. | 2444R3172 | [1] | ||
| 10. | 2444R3173 | [1] | ||
| 11. | 2444Z4656 | [2] | ||
| 12. | 2414T5925 | [4] | (not shown) | (not shown) |
| 13. | 2414T5926 | [2] | (not shown) | (not shown) |
| 14. | 2444Z4659 | [2] |
