神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (09-001) - VANDALISM GUARD ASSY, CAB Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
212 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J14359F2 | [1] | CAB (OPTION - N.A.) | CAB (OPTION - N.A.) |
| 1. | 2427P3803 | [1] | | |
| 2. | 2427P3804 | [1] | | |
| 3. | 2427P3805 | [1] | | |
| 4. | 2427P3814 | [1] | GUARD | KOB |
| 5. | 2427P3806 | [1] | | |
| 5-5. | 2416Z487D4 | [1] | CUSHION | KOB |
| 6. | 2427P3807 | [1] | | |
| 6-5. | 2416Z487D4 | [1] | CUSHION | KOB |
| 7. | 2427P3808 | [1] | | |
| 7-5. | 2416Z487D4 | [1] | CUSHION | KOB |
| 8. | 2427P3809 | [1] | GUARD | KOB |
| 10. | 2427P3815 | [1] | GUARD | KOB |
| 11. | 2427P3816 | [1] | GUARD | KOB |
| 12. | 2427P3811 | [1] | | |
| 13. | 2427P3812 | [1] | | |
| 13-4. | 2416Z487D4 | [1] | CUSHION | KOB |
| 14. | 2427P3813 | [1] | | |
| 14-4. | 2416Z487D4 | [1] | CUSHION | KOB |
| 16. | 2427P3870 | [1] | GUARD | KOB |
