纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (7.026[01]) - NAME PLATE INSTALLATION, (EXTERIOR) (YN22TU0023F1), FIGURE 1 OF 3 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
203 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 5. | YN20T01961P1 | [1] | LABEL | KOBDecal, Cylinder and Manual |
| 7. | YN20T01003P2 | [2] | LABEL | KOBDecal, Danger, Keep clear of swing area … |
| 9. | YN20T01964P1 | [1] | ANTI-SKID STRIP,500mm x 250mm | KOBDecal, Anti-Slip (250x500mm) |
| 10. | YN20T01965P1 | [2] | ANTI-SKID STRIP,400mm x 200mm | KOBDecal, Anti-Slip (200x400mm) |
| 11. | YN20T01976P1 | [1] | Decal, Anti-Slip (200x300mm) | |
| 12. | YN20T01967P1 | [1] | ANTI-SKID STRIP,850mm x 100mm | KOBDecal, Anti-Slip (850x100mm) |
| 16. | YN20T01972P1 | [1] | LABEL | KOBDecal, Rotating fan direction and hand |
| 21. | YN22T00366P1 | [2] | IDENTITY PLATE | KOBDecal, New Holland logo |
| 26. | YN22TU1002P1 | [1] | DECAL | KOBNew Holland logo 1616mm Long (63-5/8 in) |
