纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (7.026[02]) - NAME PLATE INSTALLATION, (EXTERIOR) (YN22TU0023F1), FIGURE 2 OF 3 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
973 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN20TU1040P2 | [1] | DECAL | KOBDecal, Tag, Model, Serial Number, Manufacturing Year |
| 2. | 4020Z64 | [12] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 3. | YN20T01959P1 | [1] | DECAL | KOBDecal, db Value |
| 4. | YN20T01960P1 | [1] | DECAL | KOBDecal, Lubrication |
| 14. | YN20T01967P1 | [1] | ANTI-SKID STRIP,850mm x 100mm | KOBDecal, Anti-Slip (850x100mm) |
| 15. | YN20T01971P1 | [1] | Decal, Lock out and tag out | |
| 17. | YN20T01974P1 | [1] | DECAL | KOBDecal, Caution see manual |
| 18. | YN20T01975P1 | [1] | DECAL | KOBDecal, Caution load drop, lock |
| 24. | YN20T01977P1 | [1] | DECAL | KOBDecal, Vision 2000, ISO 14001 & ISO 9001 |
| 26. | YN20T01979P1 | [2] | LABEL | KOBDecal, Do not spill liquids |
| 27. | YN20T01980P1 | [1] | DECAL | KOBDecal, Lock and unlock (15x65mm) |
| 28. | YN20T01981P1 | [1] | DECAL | KOBDecal, 12V |
| 29. | YN20T01982P1 | [1] | DECAL | KOBDecal, Rectangle and man figure |
| 30. | YN20T01983P1 | [1] | DECAL | KOBDecal, Caution hot |
