纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.009[00]) - VALVE ASSEMBLY,CONTROL (YN30V00108F1) (HC120) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
246 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN30V00108F1 | [1] | HYDRAULIC VALVE | SMAssembly, Control |
| 101. | NA | [1] | NOT SERVICED | FORCase |
| 121. | YN30V00108S121 | [1] | PLATE | SM |
| 151. | 2436U1832S651 | [1] | PLUG | KOBM18x1.5mm |
| 152. | YW30V00001S155 | [1] | PLUG | KOB1/2" |
| 153. | 2441U722S490 | [1] | PLUG | KOB1/16" NPTF |
| 154. | YN30V00108S154 | [1] | PLUG | SM1/4" |
| 155. | YW30V00001S156 | [1] | PLUG | KOB3/8" |
| 161. | ZD12P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 162. | ZD12P01800 | [1] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 163. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 164. | ZD12P01500 | [6] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 166. | ZD12P01100 | [1] | O-RING | KOBID 10.80 ± 0.18 x OD 15mm |
| 167. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 261. | YN30V00108S261 | [2] | O-RING | SM Superseded by part number: ZD12A02100 |
| 271. | YN35V00017S171 | [8] | SCREW,Hex Socket Head, M5 x 16mm | KOBScrew -- M05 Superseded by part number: ZS23C05016 |
| 322. | EM30V00001S321 | [2] | SPRING | SM |
| 331. | YA30V00002S331 | [2] | SEAL | SM |
| 332. | YA30V00002S332 | [2] | SEAT/SLOT | SM |
| 511. | YA30V00002S511 | [1] | VALVE POPPET | SM |
| 521. | YA30V00002S521 | [1] | SPRING | SM |
| 551. | YA30V00002S551 | [1] | PLUG | SMM18x1.5mm |
| 601. | YN22V00040F1 | [1] | HYDRAULIC VALVE | SMAssembly, Relief -- See Figure 8.009.01 |
| 602. | YN22V00041F1 | [2] | HYDRAULIC VALVE | SMAssembly, Relief -- See Figure 8.009.02 |
| 701. | ZS23C12025 | [4] | CAPSCREW,Hex Socket Head, M12 x 52mm | KOBSCREW M12x1.75x25mm |
| 702. | ZS23C08080 | [4] | CAP,Hex Socket Head, M8 x 80mm | KOBScrew -- M08x1.25x80mm |
