纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.012[00]) - VALVE ASSEMBLY, (SWING-REACTIONLESS) (YN20V00004F1, F2, F3 & F4) (HC315) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
326 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN20V00004F1 | [1] | VALVE | KOBAssembly, Swing-Reactionless Control |
| . . | YN20V00004F2 | [1] | VALVE | KOBAssembly, Swing-Reactionless Control |
| . . | YN20V00004F3 | [1] | VALVE | KOBAssembly, Swing-Reactionless Control |
| . . | YN20V00004F4 | [1] | CONTROL VALVE | KOBAssembly, Swing-Reactionless |
| 100. | LQ15V00001S100 | [1] | CASE | KOB(F1,F2 & F4 Only) |
| 151. | YW30V00001S157 | [2] | PLUG | KOB |
| 161. | ZD12P01100 | [2] | O-RING | KOBID 10.80 ± 0.18 x OD 15mm |
| 162. | ZD12P01200 | [2] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm -- (F1,F2 & F3 Only) |
| 163. | ZD12P00600 | [2] | O-RING | KOBID 05.80 ± 0.15 x OD 9mm -- (F1,F2 & F3 Only) |
| 164. | YT10V00003S711 | [2] | O-RING | KOB(F4 Only) |
| 165. | YN10V01006S011 | [2] | O-RING | KOB(F4 Only) |
| 400. | YN20V00004S400 | [2] | VALVE | KOB(F1 & F4 Only) |
| 401. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 403. | ZD85P02000 | [2] | RING | KOBBack-Up -- ID 20 x OD 24 x Th 1.25mm |
| 404. | YN20V00004S404 | [2] | VALVE | KOB(F2 & F3 Only) |
| 405. | YN20V00004S405 | [1] | CASE | KOB(F3 Only) Superseded by part number: YN20V00004F3 |
