纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.013[00]) - VALVE ASSEMBLY, RELIEF (YN22V00014F1-FB) (HC325) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
243 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN22V00014F1 | [1] | VALVE | KOBAssembly, Relief, Start Serial: 6 |
| . . | YN22V00014F2 | [1] | VALVE | KOBValve Assembly, Relief |
| . . | YN22V00014F3 | [1] | VALVE | KOBAssembly, Relief |
| . . | YN22V00014F4 | [1] | VALVE | KOBAssembly, Relief |
| . . | YN22V00014F7 | [1] | VALVE | KOBAssembly, Relief |
| . . | YN22V00014F8 | [1] | VALVE | KOBValve Assembly, Relief |
| . . | YN22V00014FA | [1] | VALVE | KOBAssembly, Relief |
| . . | YN22V00014FB | [1] | VALVE | KOBValve Assembly, Relief |
| 101. | NA | [1] | NOT SERVICED | FORBody |
| 161. | ZD12G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
