纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.014[00]) - PUMP ASSEMBLY (YN10V00036F1) (HC400) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
523 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN10V00036F1 | [1] | PUMP | KOBAssembly, Start Serial: 0 Superseded by part number: YN10V00036F4 |
| 1. | YN10V00043F1 | [1] | HYDRAULIC PUMP | SMAssembly -- See Figure 8.015 (HC405) |
| 2. | YN10V01009F1 | [2] | SPEED GOVERNOR | SMRegulator Assembly -- See Figure 8.017 (HC410) Superseded by part number: YN10V01009F4 |
| 3. | YN35V00052F1 | [2] | VALVE | KOBAssembly, Solenoid -- See Figure 8.018 (HC415) Superseded by part number: YN35V00054F1 |
| 4. | YN10V00014F3 | [1] | PUMP | KOBAssembly, Gear -- See Figure 8.019 (HC420) |
| 5. | YN10V00043S326 | [1] | COVER | KOB Superseded by part number: YN10V00023S009 |
| 6. | ZS23C10020 | [4] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
