纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.017[02]) - REGULATOR ASSEMBLY (YN10V01009F1) (HC410), FIGURE 2 OF 2 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
901 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN10V01009F1 | [1] | SPEED GOVERNOR | SMRegulator Assembly -- Figure 2 of 2 Superseded by part number: YN10V01009F4 |
| 412. | ZS23C08050 | [2] | CAP,Hex Socket Head, M8 x 50mm | KOBScrew -- M08x1.25x50mm |
| 413. | ZS23C08070 | [2] | SCREW,Hex Socket Head, M8 x 70mm | KOBM08x1.25x70mm |
| 418. | YX35V00002S171 | [2] | SCREW,Hex Socket Head, M5 x 12mm | KOBM05x0.8x12mm Superseded by part number: ZS23C05012 |
| 438. | ZS28C06020 | [8] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm |
| 439. | ZS23C06025 | [5] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 466. | 2441U667S466 | [3] | PLUG | KOB1/4" PF |
| 496. | 2441U722S490 | [18] | PLUG | KOB1/16" NPTF |
| 541. | NA | [2] | NOT SERVICED | FORSeat |
| 708. | YX10V01001S010 | [1] | O-RING | KOB |
| 722. | YN10V01006S011 | [3] | O-RING | KOB |
| 724. | YX10V00003S015 | [8] | O-RING,1.9mm Thk x 8.8mm ID, 75 Duro | KOB |
| 725. | YN10V01006S013 | [1] | O-RING | KOB |
| 728. | YT10V00003S708 | [1] | O-RING | KOB |
| 730. | YZ10V00002S732 | [1] | O-RING | KOB |
| 732. | YW10V00003S732 | [1] | O-RING | KOB |
| 733. | YN10V01009S733 | [4] | O-RING | KOB |
| 734. | YN10V01006S019 | [1] | O-RING | KOB |
| 753. | YN10V01006S020 | [1] | O-RING | KOB |
| 755. | YT10V00003S710 | [7] | O-RING | KOB |
| 756. | YN10V01006S022 | [1] | O-RING | KOB |
| 757. | YX10V01001S015 | [1] | O-RING | KOB |
| 763. | YN10V00003S702 | [1] | O-RING | KOB |
| 801. | ZN18C08005 | [1] | NUT | KOBM08x1.25mm |
| 814. | 2436U2455S814 | [1] | RING | KOB Superseded by part number: ZR16X01000 |
| 858. | ZR26X01500 | [2] | RING | KOBRetaining -- ID 15 x OD 16.2 x Th 1.0mm |
| 924. | 2441U722S924 | [1] | SET SCREW | KOB |
| K. | 2437U219S41 | [1] | REPAIR KIT | KOBContains Items 541X1, 543X1, 545X1 |
