纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.018[00]) - VALVE ASSEMBLY, SOLENOID (YN35V00052F1) (HC415) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
719 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN35V00052F1 | [1] | VALVE | KOBSolenoid Assembly Superseded by part number: YN35V00054F1 |
| 1. | NA | [1] | NOT SERVICED | FORSpool |
| 5. | YN35V00004S361 | [1] | O-RING | KOB |
| 6. | YN35V00004S362 | [1] | O-RING | KOB |
| 7. | YN35V00004S363 | [1] | O-RING | KOB |
| 9. | YN35V00018S802 | [1] | NUT | KOB |
| 10. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
