神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-037) - VALVE ASSY. PILOT 2436U2755F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
836 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U2755F1 | [1] | PILOT VALVE | KOBASSEMBLY Superseded by part number: 2436U2755F3 |
| . . | 2436U2755F3 | [1] | PILOT VALVE | KOB |
| 1. | 2436U1142S13 | [4] | SHIM | KOB |
| 2. | 2436U1487S7 | [4] | SHIM | KOB |
| 3. | NSS | [2] | NOT SOLD SEPARAT | CONFILTER |
| 4. | 2436U2755S4 | [2] | SEAT | KOB |
| 5. | 2436R906S7 | [2] | PLUG | KOB |
| 6. | NSS | [4] | NOT SOLD SEPARAT | CONSPOOL |
| 7. | 2436U1354S5 | [4] | SLEEVE | KOB |
| 8. | 2436U1354S6 | [2] | COVER | KOB |
| 9. | NSS | [4] | NOT SOLD SEPARAT | CONROD, PUSH |
| 10. | 2436U1354S9 | [2] | PIN | KOB |
| 11. | 2436U1354S10 | [2] | BOOT | KOB |
| 12. | 2436U2888S10 | [4] | SPRING | KOB |
| 13. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 14. | NSS | [2] | NOT SOLD SEPARAT | CONSLEEVE, F1 ONLY |
| 15. | 2436U2755S15 | [1] | NAME PLATE | |
| 16. | YN30V00004S012 | [2] | PLATE | |
| 17. | 2436U1354S4 | [4] | SPRING | KOB |
| 18. | 2436U1354S8 | [2] | CAM | KOBF1 ONLY |
| 19. | 2436U1354S25 | [4] | SHIM | KOB |
| 21. | 2436U2412S26 | [6] | PLUG | KOB1/4"PF |
| 22. | YN30V00004S022 | [4] | CAPSCREW | |
| 23. | ZS23C12020 | [2] | CAPSCREW,Hex Socket Head, M12 x 20mm | KOBM12x1.75x20mm |
| 24. | 2436U1354S15 | [4] | BOLT | KOB |
| 25. | 2436U1354S16 | [4] | WASHER | KOB |
| 26. | 2436U1354S17 | [8] | WASHER | KOBF1 ONLY |
| 27. | 2436U2888S24 | [4] | PIN | KOB |
| 28. | ZP16K02520 | [4] | COTTER PIN | KOBF1 ONLY |
| 29. | NSS | [7] | NOT SOLD SEPARAT | CONBALL |
| 30. | NSS | [6] | NOT SOLD SEPARAT | CONBALL |
| 31. | ZD11P01000 | [4] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 32. | ZD12P00900 | [2] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 33. | ZD12P01100 | [6] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 34. | ZD12P02400 | [4] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 35. | 2436R906S12 | [2] | O-RING | KOB |
| 37. | 2436U1354S26 | [4] | PISTON | KOBCONSISTS OF REF 9 & 30 |
| 38. | 2436U2755S38 | [2] | FILTER ASSY | KOBCONSISTS OF REF 3 & 14 |
| 39. | 2436U2755S39 | [1] | BODY | KOBCONSISTS OF REF 13 & 29 |
| 42. | 2436U2755S42 | [1] | NAME PLATE, F2 ONLY | |
| 43. | YN30V00022S015 | [2] | CAM | KOBF2 ONLY |
| 44. | YN30V0000S016 | [2] | BOOT, F2 ONLY | |
| 45. | YN30V00022S017 | [2] | PIN | KOBF2 ONLY |
| 46. | ZS83C08008 | [4] | SCREW | KOBSet -- M08x1.25x08mm, F2 Only |
