神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-038) - DOZER PILOT VALVE ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
327 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U3059F1 | [1] | PILOT VALVE | KOBASSY, DOZER |
| 1. | 2436U3059S001 | [1] | CASING | |
| 2. | 2436U3059S002 | [1] | PLATE, PORT | |
| 3. | 2436U3059S003 | [2] | WASHER, SEAL | |
| 4. | 2436U3059S004 | [1] | O-RING | |
| 5. | 2436U3059S005 | [2] | SCREW, HEX | |
| 6. | 2436U3059S006 | [1] | PIN, SPRING | |
| 7. | 2436U3059S007 | [1] | BUSHING | |
| 8. | 2436U3059S008 | [1] | PLATE | |
| 9. | 2436U3059S009 | [1] | SPOOL | |
| 10. | 2436U3059S010 | [4] | PLUG | |
| 11. | 2436U3059S011 | [4] | ROD, PUSH | |
| 12. | 2436U3059S012 | [4] | SEAL | |
| 13. | 2436U3059S013 | [4] | O-RING | |
| 14. | 2436U3059S014 | [4] | WASHER 1 | |
| 15. | 2436U3059S015 | [8] | SEAT, SPRING | |
| 16. | 2436U3059S016 | [4] | WASHER 2 | |
| 17. | 2436U3059S017 | [4] | SPRING | |
| 18. | 2436U3059S018 | [4] | SPRING | |
| 19. | 2436U3059S019 | [4] | JOINT | |
| 20. | 2436U3059S020 | [1] | PLATE, CIRC | |
| 21. | 2436U3059S021 | [1] | NUT, ADJUST | |
| 22. | 2436U3059S022 | [1] | BUSHING | |
| 23. | 2436U3059S023 | [1] | BELLOWS | |
| . . | 2436U3059S024 | [1] | SEAL KIT | KOBSUB, CONSISTS OF REF 121, 122, 213 & 214 |
