纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.020[00]) - PUMP ASSEMBLY (YN10V00040F1) (HC500) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
750 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN10V00040F1 | [1] | PUMP | KOBAssembly Superseded by part number: YN10V00040F2 |
| 1. | YN10V00043F1 | [1] | HYDRAULIC PUMP | SMAssembly -- See Figure 8.015 (HC405) |
| 2. | YN10V01009F1 | [2] | SPEED GOVERNOR | SMRegulator Assembly -- See Figure 8.017 (HC410) Superseded by part number: YN10V01009F4 |
| 3. | YN35V00052F1 | [2] | VALVE | KOBAssembly, Solenoid -- See Figure 8.018 (HC415) Superseded by part number: YN35V00054F1 |
| 4. | YN10V00014F3 | [1] | PUMP | KOBAssembly, Gear -- See Figure 8.019 (HC420) |
| 5. | YN46W00001F2 | [1] | GEAR | KOBAssembly, Gear -- See Figure 8.021 (HC525) |
