纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.024[00]) - CYLINDER ASSEMBLY, ARM (YN01V00172F1) (HC651) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1009 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NA | [1] | NOT SERVICED | FORTube, Cylinder |
| 4. | 2438U1018S4 | [1] | BUSHING | KOB |
| 5. | 2438U776S5 | [1] | SNAP RING | KOB |
| 6. | YN01V00175S006 | [1] | RING | KOBBuffer |
| 7. | YN01V00175S007 | [1] | RING | KOBU-Ring |
| 8. | YN01V00105S008 | [1] | BACK-UP RING | KOB |
| 9. | YN01V00105S009 | [1] | RING | KOB |
| 10. | ZD12G13000 | [1] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOBID 129.40 ± 1.05 x OD 135mm |
| 11. | LQ01V00001S011 | [1] | RING | KOB |
| 12. | ZS23C20080 | [12] | SCREW,Hex Socket Head, M20 x 80mm | KOBM20x2.5x80mm |
| 13. | YN01V00175S013 | [1] | BEARING | KOBCushion |
| 14. | YN01V00175S014 | [1] | SEAL | KOBCushion |
| 15. | YN01V00175S015 | [1] | PISTON | KOB |
| 16. | LQ01V00001S016 | [1] | RING | KOB |
| 17. | LQ01V00001S017 | [2] | BACK-UP RING | KOB |
| 18. | YN01V00175S018 | [2] | RING | KOBSide |
| 19. | LQ01V00001S019 | [2] | RING | KOB |
| 20. | 2438U953S21 | [1] | SET SCREW | KOB |
| 21. | 2436R624S6 | [1] | BALL | KOB |
| 22. | YN01V00175S022 | [1] | BEARING | KOBCushion |
| 23. | LQ01V00007S025 | [1] | SEAL | KOB |
| 24. | 2438U1104S25 | [2] | STOP | KOB |
| 25. | 2438U1104S26 | [1] | RING | KOB |
| 26. | YN01V01108P1 | [4] | BUSHING,85mm ID x 95mm OD x 54.5mm L | SMBushing |
| 27. | 2438U1102S26 | [4] | SEAL | KOB |
| K. | YN01V00175R100 | [1] | SEAL | SMRepair Rod Side -- Contains Items 6X1, 7X1, 8X1, 9X1, 10X1, 11X1 |
| K. | YN01V00175R200 | [1] | SEAL | SMRepair Piston Side -- Contains Items 14X1, 16X1, 17X2, 18X2, 19X2, 23X1 |
| K. | YN01V00175R300 | [1] | SEAL | SMRepair All (Rod+Piston) -- Contains Items 6X1, 7X1, 8X1, 9X1, 10X1, 11X1, 14X1, 16X1, 17X2, 18X2, 19X2, 23X1 |
| K. | YN01V00175R400 | [1] | SEAL | SMRepair -- Contains Items 1X1, 26X2, 27X2 |
| K. | YN01V00175R500 | [1] | REPAIR KIT | SMRepair -- Contains Items 2X1, 26X2, 27X2 |
