纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.024[01]) - CYLINDER ASSEMBLY, ARM (EXTREME REACH) (YN01V00132F4) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
749 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN01V00132F4 | [1] | HYDRAULIC CYLINDER | KOBArm (Extreme Reach) |
| 3. | YN01V00105S003 | [1] | CYLINDER HEAD | KOB |
| 4. | 2438U1018S4 | [1] | BUSHING | KOB |
| 5. | 2438U776S5 | [1] | SNAP RING | KOB |
| 6. | YN01V00132S037 | [1] | BACK-UP RING | KOB |
| 7. | YN01V00105S007 | [1] | RING | KOB |
| 8. | YN01V00105S008 | [1] | BACK-UP RING | KOB |
| 9. | YN01V00105S009 | [1] | RING | KOB |
| 10. | ZD12G13000 | [1] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOBID 129.40 ± 1.05 x OD 135mm |
| 11. | LQ01V00001S011 | [1] | RING | KOB |
| 12. | ZS23C18080 | [12] | CAPSCREW,Hex Socket Head, M18 x 80mm | KOBSCREW M18x2.50x80mm |
| 13. | YN01V00105S013 | [1] | BUSHING | KOB |
| 14. | YN01V00105S014 | [1] | SEAL | KOB |
| 15. | YN01V00105S015 | [1] | PISTON | KOB |
| 16. | LQ01V00001S016 | [1] | RING | KOB |
| 17. | LQ01V00001S017 | [2] | BACK-UP RING | KOB |
| 18. | YN01V00105S018 | [2] | RING | KOB Superseded by part number: YN01V00105S050 |
| 19. | LQ01V00001S019 | [2] | RING | KOB |
| 20. | 2438U1170S20 | [1] | SHIM | KOB |
| 21. | YN01V00118S021 | [1] | NUT | KOB |
| 22. | 2438U953S21 | [1] | SET SCREW | KOB |
| 23. | 2436R624S6 | [1] | BALL | KOB |
| 24. | YN01V00105S024 | [1] | LOCK NUT | KOB |
| 25. | LQ01V00007S025 | [1] | SEAL | KOB |
| 26. | 2438U1104S25 | [2] | STOP | KOB |
| 27. | 2438U1104S26 | [1] | RING | KOB |
| 29. | 2438U1102S26 | [4] | SEAL | KOB |
| 30. | YN01V00105S030 | [1] | BAND | KOB |
| 31. | 2438U1018S28 | [1] | BAND | KOB |
| 32. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 33. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 35. | YN01V01076P1 | [2] | BUSHING | KOB |
| K. | YN01V00105R100 | [1] | REPAIR KIT | KOBHead -- Contains Items 6-8 & 9-11 |
| K. | YN01V00105R800 | [1] | REPAIR KIT | KOBPiston -- Contains Items 14, 16, 17-19 & 25 |
| K. | YN01V00105R900 | [1] | REPAIR KIT | KOBHead & Piston -- Contains Items 6-8, 9-11, 14, 16, 17-19 & 25 |
| K. | YN01V00105R600 | [1] | REPAIR KIT | KOBCylinder -- Contains Items 1, 29 & 35 |
| K. | YN01V00118R500 | [1] | REPAIR KIT | KOBRod -- Contains Items 2, 28 & 29 |
