神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-041) - GRIP ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
519 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM03MU1008F1 | [1] | GRIP | KOBInc. 1-5 |
| . . | YM03MU1008F2 | [1] | GRIP | KOBInc. 1-5 |
| 1. | YM03MU1005P1 | [1] | GRIP | |
| 2. | YM03MU1003P1 | [1] | LEVER | |
| 3. | YM03MU1007P1 | [1] | GROMMET | |
| 4. | YM03MU1008S004 | [1] | PIN, SPRING | |
| 5. | YM03MU1008S005 | [1] | NUT | |
| 6. | YM03MU1008S006 | [1] | ELEC CONNECTOR | KOBHOUSING |
| 7. | YM03MU1008S007 | [1] | RETAINER | |
| 8. | YM03MU1008S008 | [6] | TERMINAL | |
| 9. | YM03MU1008S009 | [6] | PLUG | |
