沃尔沃零件查询5.0GLPBYC; 5.0GiPBYCCE; 5.7GSPBYC; 5.7GSIPBYCCEElectrical SystemEngine Harness BracketEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
823 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3854186
|
[1] |
Automatic fuse
|
60A
|
| 1. |
3854282
|
[2] |
Switch
|
12,5A
|
| 1. |
3854164
|
[1] |
Automatic fuse
|
50A
|
| 1. |
3854163
|
[1] |
Automatic fuse
|
20A
|
| 1. |
3854238
|
[1] |
Automatic fuse
|
6A
|
| 2. |
3852182
|
[1] |
Washer
|
|
| 3. |
3852064
|
[8] |
Nut, circuit breaker terminals
|
|
| 4. |
3853620
|
[8] |
Hexagon screw
|
|
| 5. |
3852001
|
[8] |
Tab washer, circuit breaker terminals
|
|
| 6. |
3852825
|
[1] |
Retainer, engine cable
|
|
| 7. |
3852208
|
[3] |
Screw, retainer, engine cable end to bracket
|
|
| 8. |
3854138
|
[1] |
Relay, starter motor
|
|
| 9. |
3850234
|
[1] |
Rubber cushion, relay mounting
|
|
| 10. |
3852118
|
[1] |
Nut, relay to isolator
|
|
| 11. |
3855938
|
[4] |
Screw, circuit breaker and engine cable
|
|
| 12. |
3856186
|
[1] |
Bracket
|
|
| 13. |
3856764
|
[1] |
Cover, circuit breaker bracket
|
|
| 14. |
941263
|
[4] |
Grommet
|
|
