沃尔沃零件查询5.0GLPBYC; 5.0GiPBYCCE; 5.7GSPBYC; 5.7GSIPBYCCEEngineCylinder HeadEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
513 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3857663
|
[2] |
Cylinder head
|
|
| 2. |
3853146
|
[16] |
Stud, rocker arm, 0.003 in. os
|
0.08mm
|
| 2. |
3853147
|
[1] |
Stud, rocker arm, 0.013 in. os
|
0.33mm; as required
|
| 3. |
3855808
|
[8] |
Valve, exhaust
|
other
|
| 3. |
3855809
|
[1] |
Valve, exhaust
|
O.S=0.030''
|
| 4. |
3857666
|
[8] |
Valve, intake
|
other
|
| 5. |
3853311
|
[2] |
Bracket, lift
|
|
| 6. |
3855816
|
[8] |
Valve cap, Valve spring
|
|
| 7. |
3855823
|
[32] |
Valve cotter, valve stem
|
|
| 8. |
3856139
|
[8] |
Guide, valve lifter
|
|
| 9. |
3856215
|
[1] |
Valve
|
|
| 10. |
3855815
|
[16] |
Valve spring
|
|
| 11. |
3856127
|
[16] |
Tappet
|
|
| 12. |
3856124
|
[16] |
Bolt
|
L=1,62'' (41mm)
|
| 12. |
3856123
|
[4] |
Bolt
|
L=3 1/16'' (78mm)
|
| 12. |
3856122
|
[14] |
Bolt
|
L=3 51/64'' (96mm)
|
| 13. |
3856118
|
[16] |
Push rod
|
|
| 14. |
3853158
|
[16] |
Arm
|
|
| 15. |
3855814
|
[8] |
Valve stem seal, valve stem, intake
|
|
| 15. |
3857648
|
[8] |
Valve stem seal, valve stem, exhaust
|
|
| 16. |
3852687
|
[2] |
Gasket, valve cover
|
|
| 17. |
3856927
|
[1] |
Valve cover, port
|
|
| 17. |
3856928
|
[1] |
Valve cover, stbd
|
|
| 18. |
3853326
|
[1] |
Flange screw, lift & fuel bracket to head
|
|
| 18. |
3853557
|
[3] |
Flange screw, lift bracket, clamps to head
|
|
| 19. |
3856135
|
[8] |
Bolt, valve cover
|
|
| 20. |
3852104
|
[1] |
Elbow, valve cover
|
|
| 21. |
3853380
|
[2] |
Cylinder head gasket, cylinder head
|
|
| 22. |
3851857
|
[2] |
Spark plug kit, 4 pack
|
|
| 22. |
3851858
|
[1] |
Spark plug kit, 24 pack
|
|
| 23. |
3854008
|
[1] |
Oil filler cap
|
|
| 24. |
3852103
|
[2] |
Grommet, valve cover
|
|
