神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (12-022) - PUMP ASSEMBLY, GEAR (2437U507F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
251 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2437U507F1 | [1] | PUMP | KOBAssembly |
| . . | 2437U507F1R | [1] | REMAN-HYD PUMP | RACED180 BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001, Assembly |
| . . | 2437U507F1C | [1] | CORE-HYDRAULIC PUMP | RACReturn Number |
| 1. | 2437U507S1 | [1] | BODY | KOB |
| 2. | 2437U507S2 | [1] | COVER- SUB'D | COVER- SUB'D |
| 4. | 2437U507S4 | [1] | GEAR | KOB |
| 5. | 2437U507S5 | [1] | GEAR | KOB |
| 9. | 2437U507S9 | [4] | WASHER | KOB |
| 11. | 2437U507S11 | [4] | SCREW | KOB |
| 12. | 2437U507S12 | [1] | PLUG | KOB |
| 13. | 2437U507S13 | [2] | PIN | KOB |
| . . | 2437U507R100 | [1] | SEAL KIT | KOB |
