纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.032[00]) - VALVE ASSEMBLY, SOLENOID (LS35V00002F1) (HC860) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
173 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LS35V00002F1 | [1] | VALVE | KOBAssembly, Solenoid |
| 101. | YM35V00001S101 | [1] | Body | |
| 171. | YX35V00002S171 | [2] | SCREW,Hex Socket Head, M5 x 12mm | KOB Superseded by part number: ZS23C05012 |
| 601. | LS35V00004F1 | [1] | VALVE | KOBAssembly, Solenoid See Figure 8.034 (HC861) |
| 901. | YY35V00007S901 | [1] | Name Plate | |
