神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (01-003) - COUNTERWEIGHT ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
229 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N9222F1 | [1] | COUNTERWEIGHT ASSY | |
| 1. | 24100P4953F1 | [1] | COUNTERWEIGHT ASSY | |
| 1-1. | YM60CU0002P1 | [1] | | |
| 1-3. | 2427Z2048 | [1] | INSULATION | |
| 2. | 2414P9691 | [1] | COVER | KOB |
| 3. | 2418P26487D2 | [1] | PLATE | KOB |
| 4. | 2418P26487D1 | [1] | PLATE | KOB Superseded by part number: 2418N3902 |
| 5. | 2418T12306D2 | [2] | SHIM | KOB0.6 |
| 6. | 2418T12306D3 | [2] | SHIM | KOB0.4 |
| 7. | 2418T12306D5 | [2] | SHIM | KOB2.3 |
| 8. | 2418T12306D6 | [8] | SHIM | KOB1.6 |
| 9. | 2420Z1340D4 | [2] | PLUG | KOBOD 46 x 30mm Long |
| 10. | 2420T8293D1 | [4] | SCREW | KOB(M24 x 315) |
| 11. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 12. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 13. | ZW13H24000 | [8] | WASHER | KOBID 24 x OD 39 x Th 4.0mm |
| 14. | 2418T21031 | [4] | WASHER | KOB(M10) |
| 15. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 16. | ZN13C24019 | [4] | NUT | KOBM24x3.0mm |
| 17. | 2420T6786 | [4] | BOLT,M12 x 1.75 x 25mm | KOBM12x1.75x25mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12025 |
