神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (01-004) - SWING MOTOR ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
929 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J16122F3 | [1] | MOTOR ASSY, SWING | MOTOR ASSY, SWING |
| 20. | ZR16X04500 | [1] | RING | KOBRetaining -- ID 45 x OD 58 x Th 1.8mm |
| 39. | 2441U819F3 | [1] | HYDRAULIC MOTOR | KOBASSY |
| 39-1. | 2441U804F1 | [1] | HYDRAULIC MOTOR | KOBSWING (SEE CPM) |
| 39-2. | 2436U1283F1 | [1] | VALVE PRESSURE RELIE | KOBREDUCTION (SEE CPM) |
| 39-3. | ZS23C12135 | [4] | SCREW,Hex Socket Head, M12 x 135mm | KOBM12x1.75x135mm |
| 39-4. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 39-5. | 2436U1431F6 | [1] | CONTROL VALVE | KOB(SEE CPM) |
| 45. | 24100J16328F3 | [1] | HYDRAULIC MOTOR | KOB |
| 45-1. | 2410J552 | [1] | FINGER ASSY. | KOB |
| 45-2. | 2418P29712 | [1] | HOSE | KOBSLEEVE |
| 45-3. | 2418P29713 | [1] | RETAINER | KOB |
| 45-4. | 2414J2298 | [1] | HOUSING | KOB |
| 45-5. | R25P0047D8 | [1] | BEARING | KOB |
| 45-6. | 25Z494D11 | [1] | BEARING | KOBROLLER |
| 45-7. | 2413J381 | [1] | DIFF. SPIDER | KOBSPIDER |
| 45-8. | 2413N462F1 | [1] | SPIDER | KOB |
| 45-9. | 2410T340 | [4] | ROLLER SHAFT | KOB |
| 45-10. | 2401N468 | [1] | RING GEAR | KOB |
| 45-11. | 2401P1276 | [1] | SUN GEAR | KOB |
| 45-12. | 2401P1277 | [4] | PINION | KOB |
| 45-13. | 2401P1440 | [4] | PINION | KOB |
| 45-14. | ZD11G09500 | [1] | O-RING,94.40mm ID x 100.60mm OD x 3.10mm | KOBID 94.40 ± 0.81 x OD 100mm |
| 45-15. | ZS23C08030 | [12] | SCREW,Hex Socket Head, M8 x 30mm | KOBM08x1.25x30mm Superseded by part number: ZS28C08030 |
| 45-17. | 2418T20989 | [1] | SPACER | KOB |
| 45-18. | 2418P20198D3 | [2] | SPACER | KOB |
| 45-19. | 2401P1434 | [1] | SUN GEAR | KOB |
| 45-20. | ZP26D08025 | [4] | PIN | KOBRoll -- OD 08 x 25mm Long |
| 45-21. | 2418T20962 | [4] | THRUST WASHER | KOB |
| 45-22. | 2418T19775D3 | [4] | THRUST WASHER | KOB |
| 45-23. | 2425R332 | [4] | NEEDLE BEARING | KOB |
| 45-24. | 2425T384 | [140] | NEEDLE BEARING | KOBROLLER |
| 45-25. | ZR16X08500 | [1] | LOCKING RING | KOBSNAP |
| 45-26. | ZS83C20020 | [2] | SCREW | KOBSet -- M20x2.50x20mm |
| 45-27. | 2418T25314 | [8] | THRUST WASHER | KOB |
| 45-30. | ZE82T12000 | [1] | PLUG | KOB3/4" PT |
| 45-31. | 2418T20988 | [1] | SPACER | KOB |
| 45-32. | ZS23C14140 | [10] | SCREW,Hex Socket Head, M14 x 140mm | KOBM14x2.0x140mm |
| 45-33. | ZR16X04000 | [4] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 45-34. | YN32W01032P1 | [1] | COVER | KOB |
| 45-35. | ZS91C01200 | [2] | EYEBOLT | KOB |
| 45-36. | 2420T6698D3 | [1] | RIGID TUBE | KOB |
| 45-37. | ZG31U12000 | [1] | ELBOW | KOB |
| 45-38. | YN32W01034P1 | [1] | OIL SEAL | KOBReplaces YN32W01032P1 |
| . . | 24025T2F2 | [1] | SERVICE KIT | KOBNEEDLE ROLLER KIT (INCLUDES REF 45-24) |
