纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.037[00]) - VALVE ASSEMBLY, HOLDING (YN28V00019F1 & YN28V00019F2) (HC900) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
179 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN28V00019F1 | [1] | VALVE | KOBAssembly, Holding Superseded by part number: YN28V00023F1 |
| . . | YN28V00019F2 | [1] | VALVE | KOBValve Assembly, Holding Superseded by part number: YN28V00023F2 |
| 101. | NA | [1] | NOT SERVICED | FORCase |
| 161. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 162. | ZD12P02800 | [1] | O-RING | KOBID 27.70 ± 0.27 x OD 34mm |
| 163. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 164. | ZD12P01100 | [1] | O-RING | KOBID 10.80 ± 0.18 x OD 15mm |
| 165. | YN28V00019S165 | [1] | O-RING | KOB |
| 166. | YT30V00009S212 | [1] | O-RING | KOB |
| 167. | YN28V00019S167 | [1] | O-RING | KOB |
| 169. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 170. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 201. | YN28V00019S201 | [1] | PLUG | SM |
| 202. | 2436U1198S551 | [1] | PLUG | KOB Superseded by part number: YN15V00002S012 |
| 203. | YN28V00019S203 | [1] | PLUG | SM |
| 204. | YW30V00001S157 | [1] | PLUG | KOB |
| 206. | YN28V00019S206 | [2] | RING | SMRestrictor |
| 207. | YW30V00001S156 | [2] | PLUG | KOB |
| 271. | YN28V00019S271 | [1] | SEAT/SLOT | SMSpring |
| 311. | YN28V00019S311 | [1] | SUPPORT | SMPoppet |
| 321. | YN28V00019S321 | [1] | SPRING | KOB |
| 322. | YN28V00019S322 | [1] | SPRING | KOB |
| 323. | YN28V00019S323 | [1] | SPRING | KOB |
| 542. | YN28V00019S542 | [1] | BUSHING | SM |
| 631. | YN28V00019S631 | [1] | PISTON | SM |
| 632. | YN28V00019S632 | [1] | PISTON | SM |
