神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (01-006) - FUEL TANK ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
543 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N9231F1 | [1] | FUEL TANK ASSY | |
| 1. | 24100N9232F1 | [1] | TANK ASSY, FUEL | |
| 1-1. | YM20PU0002P1 | [1] | FUEL TANK | KOB |
| 1-2. | 2446R326 | [1] | FILTER STRAINER | KOB |
| 1-3. | 2444R1047 | [1] | FILLER CAP | KOB |
| 1-5. | ZE82T08000 | [1] | PLUG | KOB1/2" PT |
| 4. | 2444Z3688 | [1] | COCK | KOBDRAIN |
| 6. | 2418T9962 | [1] | PACKING | KOBID 41 x OD 68 x Th 2.0mm |
| 7. | ZS31C05012 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBM05x0.8x12mm |
| 8. | ZW26X05000 | [5] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 10. | ZS13C16035 | [4] | SCREW | KOBM16x2.0x35mm |
| 11. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 12. | 2418T17283D1 | [3] | SPACER | KOB(T1.0) |
| 13. | 2489U267F1 | [1] | SENSOR | KOBUNIT |
