神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (01-005) - HYDRAULIC TANK ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
337 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J17020F1 | [1] | RESERVOIR, HYDRAULIC | KOB |
| 2. | 2446R307F2 | [1] | STRAINER ELEMENT | KOBSUCTION |
| 2-1. | 2446R307S1 | [1] | STRAINER ASSY. | KOB Superseded by part number: YN50V00002S001 |
| 2-3. | 2446R110S2 | [1] | HOLDER | KOBPLATE |
| 2-4. | ZN11C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 2-5. | 2446R110S6 | [1] | SPRING | KOB |
| 2-6. | 45Z91D6 | [1] | O-RING | KOBID 97.79 ± 0.38 OD 108.45mm |
| 2-7. | 2446R110S5 | [1] | SCREW | KOB |
| 8. | 2446U119S3 | [1] | VALVE | KOBBY-PASS |
| 9. | 2446U119S2 | [1] | SPRING | KOB |
| 11. | 2489R293F1 | [1] | LEVEL GAUGE | KOB Superseded by part number: YN58S00009F1 |
| 11-1. | 2489R173S1 | [1] | GAUGE | KOB |
| 11-2. | 2489R174S3 | [2] | BOLT | KOBSpecial -- M10x1.50x40mm Long |
| 11-3. | 2489R174S2 | [2] | BLOCK | KOBGAUGE, LEVEL |
| 11-4. | ZD11P01800 | [4] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 11-5. | ZD11P01000 | [4] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 12. | 2489R302F1 | [1] | SWITCH | KOBLEVEL |
| 12-1. | 2489R302S1 | [1] | SWITCH | KOB Superseded by part number: 77260484, 2489R302F1 |
| 12-2. | 2489R302S2 | [1] | O-RING | KOB |
| 13. | 2418T17283D1 | [3] | SPACER | KOB |
| 14. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 15. | ZS18C06012 | [1] | SCREW,Hex, M6 x 12mm | KOBM06x1.0x12mm |
| 16. | ZS23C06012 | [3] | SCREW,Hex Socket Head, M6 x 12mm | KOBM06x1.0x12mm |
| 17. | ZS13C16030 | [4] | SCREW | KOBM16x2.0x30mm |
| 19. | ZW26X06000 | [5] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 23. | 2432R225D1 | [1] | CLIP | KOBClamp, Single -- ID 06 x 29.8mm Long |
| 29. | YR50V00004P1 | [1] | HYDRAULIC OIL FILTER | KOBRETURN Superseded by part number: YR50V00004P1P |
| 50. | 24100J17020F1-0 | [1] | HYD. TANK ASSY | HYD. TANK ASSY |
| 50-2. | 2418R23898 | [1] | FLANGE | |
| 50-3. | 2418T4572D1 | [1] | FLANGE | KOB |
| 50-4. | ZD11G16500 | [1] | O-RING,164.30mm ID x 175.70mm OD x 5.70mm | KOBID 164.30 ± 1.30 x OD 175.7mm |
| 50-5. | ZD11P13000 | [1] | O-RING | KOBID 129.6 ± 1.05 x OD 140mm |
| 50-9. | ZS18C12025 | [4] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 50-11. | ZW22K06000 | [3] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 50-12. | 2420N458D06016 | [4] | SCREW,Hex Socket Head, M6 x 16mm | KOB Superseded by part number: ZS28C06016 |
| 50-13. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 50-14. | ZE72X08000 | [1] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800) |
| 50-15. | ZE72X16000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P02900) |
| 50-16. | ZW26X12000 | [8] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 810. | YN57V00002F5 | [1] | BREATHER ASSY. | KOB Superseded by part number: YN57V00010F1 |
| 810-1. | 2446U260S1 | [1] | BODY | KOB |
| 810-6. | 2446U260S8 | [1] | PACKING | KOB |
| 810-10. | YN57V00002S010 | [1] | ELEMENT | KOB Superseded by part number: 47640920 |
| 810-11. | YN57V00002S011 | [1] | COVER | KOB |
| 810-13. | ZD11P01400 | [1] | O-RING | KOBID 13.8 ± 0.19 x OD 18.6mm |
| 810-14. | YN57V00002S014 | [1] | NUT | KOBCAP |
